Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2019, proizvajalec krmilnikov: SIEMENS, model krmilnika: 840D sl, število osi: 4, This 4-axis HELLER MC 20 was manufactured in 2019. It is equipped with a Siemens 840D sl control system, offering X, Y, and Z travel paths of 800 mm, 750 mm, and 800 mm, respectively. The spindle operates within a speed range of 5 to 16,000 rpm and provides a drive power of 34 kW. The machine includes a tool magazine with 44 positions and a rotary table diameter of 520 mm. Consider acquiring this HELLER MC 20 horizontal machining center. Contact us for further details. • Working Area: • Feed forces (X/Y/Z): 10,000 N • Speed and Dynamics: • Rapid traverse X/Y/Z: 60,000 mm/min • Acceleration: X = 7 m/s², Y = 8 m/s², Z = 6 m/s² • Spindle/Processing Unit (HSK-A63): • Tool interface: HSK-A63 • Spindle diameter at front bearing: 70 mm • Tool Management: • Tool magazine type: HSK-A63 • Number of tool stations: 44 • Max. tool weight with all positions occupied: 6 kg • Maximum tool length: 550 mm • Max. tool diameter: • With all positions occupied: 120 / 80 / 80 mm • With adjacent positions free: 150 mm • Minimum chip-to-chip time (VDI): approx. 3.3–4.4 s Rjdpfx Adsyf Nntj Tsbt • Rotary Axis: • A-axis with rotary table diameter: 520 mm • Interference diameter (A-axis): 1,260 mm • A-axis rotational speed: 17 rpm • Indexing resolution: 360,000 × 0.001° • Indexing accuracy (VDI/DGQ 3441): 12 arcseconds • Measurement system: Direct, absolute linear scales • Utilities: • Power supply: 400 V / 50 Hz • Total connected load: approx. 27–30 kVA • Compressed air supply: 4.5–6 bar • Condition and Documentation: • Machine is in excellent technical condition • Complete service documentation available Additional Equipment • Special loading and unloading system

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2001, proizvajalec krmilnikov: SIEMENS, model krmilnika: 840, skupna masa: 11.500 kg, število osi: 5, This 5-axis Gleason PFAUTER G320 CNC + Promot Automation was manufactured in 2001. It is equipped with a Siemens 840 control system, a maximum workpiece diameter of 380 mm, and a module range of 0.5–7.0. The system includes Promot Automation handling, a robotic system, and a coolant belt system. If you are looking for a high-quality gear grinding machine, you should consider the Gleason PFAUTER G320 CNC machine we are offering for sale. Contact us for further information about this machine. • Control panel: included • Module range: 0.5–7.0 • Workpiece diameter: min 10 mm, max 380 mm • Number of teeth: 10–600 • Axis travel: Z (vertical) 200 mm; X (horizontal) 230 mm; Y (tangential/shift) 135 mm • Chuck swivel (A): ±45° • Tailstock stroke: 125 mm • Dressing travel: V (tangential) 180 mm; U (radial) 110 mm • Grinding wheel speed: up to 3,000 rpm, stepless • Linear axis speed: 10,000 mm/min • Max. table speed: 240 rpm • Table resolution: 0.001° • Feed rates: machining and working feeds stepless • Grinding wheel dimensions: diameter 270–350 mm; width up to 104 mm; bore 160 mm • Machine weight: approx. 11,500 kg • Space requirement (machine): approx. 3.7 m × 2.4 m × 2.75 m Additional equipment • Promot Automation handling unit (robot handling) • Operator panel/handheld (for automation) • Conveyor • Coolant belt system • Hydraulic unit • Space requirement (automation): approx. 4.5 m × 1.6 m × 4.0 m • Accessories as shown in the photos Rbedpfx Aeyf E R Dsd Tst

Stanje: rabljeno, Leto izdelave: 1998, obratovalne ure: 95.000 h, številka stroja/vozila: IntNr231314, Dane techniczne Sterowanie CNC: FANUC 16iM-16i Godziny pracy: 95 000 h Przesuwy (X × Y × Z): ok. 500 × 380 × 300 mm Powierzchnia stołu: 650 × 380 mm Rjdpfeyfwhbox Ad Tjbt Stożek wrzeciona: ISO/BT 30 Moc wrzeciona: ok. 5,5 kW Prędkość obrotowa wrzeciona: do 8 000 obr./min Prędkość szybkiego przesuwu: ok. 48 m/min Magazyn narzędzi: ok. 14 pozycji (ISO30-BT30) Zbiornik na wióry i chłodziwo z pompą Zintegrowany układ smarowania płynem Maszyna może zostać obejrzana pod napięciem po wcześniejszym umówieniu terminu. Zmiany oraz pomyłki w danych technicznych i informacjach zastrzeżone. Zastrzega się wcześniejsza sprzedaż!

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2012, številka stroja/vozila: IntNr231419, As-new condition, completely overhauled CNC 5-axis vertical machining centre DMG DMU 40 eVo linear, year of manufacture 2012, internal no. 231419 Control system: Manufacturer: HEIDENHAIN Model: 530 Main drive: Spindle speed range: 14,000 rpm Number of axes: 5 Travels: X-axis travel: 400 mm Y-axis travel: 400 mm Z-axis travel: 375 mm Includes: - Automatic tool changer with 120 stations, SK40 tool holder - Table rotary feed-through for workpiece clamping - Side door for robotic loading - Renishaw tool breakage detection - Heidenhain probe - High-pressure coolant system (IKZ) with 600-litre tank - Emulsion extraction unit - Active spindle chiller Redpfx Adoydnnce Tjbt - Linear drives for X and Y axes - Glass scales The machine can be inspected under power by prior appointment. Subject to alterations, errors in technical data, and prior sale!

Stanje: rabljeno, Leto izdelave: 2006, številka stroja/vozila: IntNr231476, Haas Mini Mill NC-Steuerung: HAAS-CONTROLER Verfahrwege ca.: X = 406 mm, Y = 305 mm, Z = 254 mm Tischgröße ca.: 914 x 305 mm Spindeldrehzahl: 6.000 U/min / 45 Nm bei 1.200 U/min Werkzeugwechsler: 10-fach, SK40 Max. Abstand zwischen Tisch und Spindelnase: 102 – 356 mm Werkzeugmagazin: 10 Plätze Redpfjydd E Dox Ad Tobt Werkzeugvermessungssystem Drehtisch USB- & RS232-Schnittstelle Automatisches Zentralschmiersystem Programmierung mit G-/M-Codes unterstützt Werkzeugüberwachung Kühlmittelsystem Abmessungen (L x B x H): 1.880 x 2.007 x 2.692 mm Maschinengewicht: 1.542 kg Die Maschine kann nach Terminvereinbarung unter Strom besichtigt werden. Technische Daten und Angaben sind freibleibend; Änderungen, Irrtümer und Zwischenverkauf vorbehalten.

Stanje: rabljeno, Leto izdelave: 2022, obratovalne ure: 12.787 h, številka stroja/vozila: M210019, sestavljen iz: FP 600 Duo komplet, kompletna laserska postaja, SIC MARKING, tip XXL-BOX 1200, leto izdelave 2021, pralni stroj, filtrirni sistem za pralni stroj, lovilec olja, ultrazvočno čiščenje, 1 robot tipa IRB 4600, varianta IRB 4600-40/2.55, IRC5 Single Redpfjycivfex Ad Tobt

Stanje: rabljeno, Leto izdelave: 2007, številka stroja/vozila: 195125, Teža: 5.040 kg, krmiljenje MAZATROL Matrix, transporter za odvod ostružkov, menjalec orodij, maks. dolžina orodja: 210 mm, POZOR: Prevzem tega artikla samo po predhodnem dogovoru! Rjdoyciryepfx Ad Tebt

Stanje: rabljeno, Leto izdelave: 2018, obratovalne ure: 10.770 h, številka stroja/vozila: 291353, Teža: 16.500 kg, menjalnik orodij: 48-pozicijski, hodi (x/y/z): 4 mm, upravljanje: MAZATROL Smoothg, naprava za pripravo maziva, transporter za ostružke, hladilna enota, brez strojnih primežev, zaščita rezkalne vretena poškodovana, 1 žep za orodje (št. 28) pokvarjen, POZOR: prevzem te pozicije samo po dogovoru! Rbodpfx Adoycir Ho Tjt

Stanje: rabljeno, Leto izdelave: 2006, številka stroja/vozila: 184628, Teža: 7.100 kg, 30-kratni menjalec orodij, pomična T-utorna vpenjalna miza, krmilje MAZATROL 640M, hodi (x/y/z): 1 mm, sistem za pripravo maziva, transporter za ostružke, elektro omara, brez strojnih primežev. POZOR: Prevzem tega artikla le po dogovoru! Rbodpjycir Tjfx Ad Tst

Stanje: rabljeno, Leto izdelave: 2018, obratovalne ure: 12.678 h, številka stroja/vozila: 290060, Teža: 16.800 kg, menjalec orodja za 48 orodij, hodi (x/y(z)): 4 mm, z napravo za pripravo maziva, transporter za ostružke, hladilna naprava, elektro omara. POZOR: Prevzem tega artikla možen samo po dogovoru! Rodpfx Adjycitko Tebt

Stanje: rabljeno, Leto izdelave: 2014, obratovalne ure: 24.970 h, številka stroja/vozila: 15175183974, Inv. št.: 371400, pomiki X/Y/Z: 1.800x700x700 mm, maks. teža obdelovanca: 1.500 kg, hitrost vretena: 20 - 8.000 vrt/min, držalo orodja: SK40, 60-pozicijski menjalec orodij, lastna teža: 13.250 kg, s krmiljenjem SIEMENS Sinumeric 840D sl, elektronski ročni kolešček, transporter odrezkov, inv. št.: 473100, hidravlična enota, miza z T-utorom, pribl. 210x70 cm, z integrirano vrtljivo mizo, sistem ničelne točke, 4x NC primeži HILMA NC 125, 1 konzola GARANT Zeroclamp. Rbedeyciunopfx Ad Tot

Stanje: rabljeno, Leto izdelave: 2009, obratovalne ure: 30.893 h, številka stroja/vozila: 30009075, Inv. št.: 314000, pomiki X/Y/Z: 2.000x620x520 mm, maks. teža obdelovanca: 2.000 kg, navor vretena: 165 Nm, hitrost vretena: 30 - 8.000 vrt./min, menjalnik orodij za 56 orodij, lastna teža: ca. 11.500 kg, mere D׊×V: ca. 560x430x300 cm, z odvodom ostružkov AME KB 448, tračni filter AME PS120, serijska št.: 8558, sistem za čiščenje zraka LTA, krmiljenje HEIDENHAIN, z vpenjalno mizo z T-utori, ca. 250x60 cm Rbodpfx Adsyciuus Tot

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 1999, skupna masa: 70 kg, število osi: 5, Ta 5-osna TOS VARNSDORF W 100 A je bila izdelana leta 1999. Deluje z napetostjo 3PE ~ 400 V, frekvenco 50 Hz in tokom 22 A. Moč stroja je 15 kVA, teža pa 70 kg. Razmislite o nakupu tega horizontalnega obdelovalnega centra TOS VARNSDORF W 100 A. Za več informacij nas kontaktirajte. • Napetost: 3PE ~ 400 V Rbsdpfx Adoyblnuo Tot • Frekvenca: 50 Hz • Tok: 22 A • Moč: 15 kVA • Krmilna napetost: 24 V

Stanje: dober (rabljeno), Leto izdelave: 2008, številka stroja/vozila: 011657, potovalna razdalja osi X: 4.200 mm, pomik osi Y: 2.040 mm, pomik po osi Z: 700 mm, nazivna (navidezna) moč: 65 kVA, proizvajalec krmilnikov: Fanuc, model krmilnika: 18i-MB, Delovna površina 4200 x 2040 mm Krmiljenje Fanuc Obremenitev mize 7500 kg Pomik osi: X 4050 mm, Y 2100 mm, Z 700/920 mm Razmak med stebri 2400 mm Rbjdpfx Aeyabfmed Tot Obrati vretena 40-3800 Masa orodja 20 kg Magazin orodij 60 kos.

Stanje: dober (rabljeno), Leto izdelave: 1999, Funkcionalnost: popolnoma funkcionalen, Letnik: 1999 Širina: 1200 Dolžina: 1200 Število osi: 5 Držalo orodja: SK50 Hitrost vretena (Rpm): 3.500 Obdelovalni materiali: Jeklo, aluminij, titan, grafit, baker, invar, kompozit, delrin, peek Rbsdpex Uwtkefx Ad Tet

Stanje: novo, Leto izdelave: 2026, Funkcionalnost: popolnoma funkcionalen, hitrost vretena (min.): 12.000 obr/min, največja hitrost vretena: 36.000 obr/min, CNC stroji znamke HG GRIMME SysTech Popolni za: Zelo učinkovito 3D rezkanje majhnih obdelovancev – natančno rezkanje z visokim izmetom delov Materiali: Plastika, kompoziti kot so CFK / GFK, modelarska gradiva, aluminij Rjdsx S Etmopfx Ad Tjbt Panoge: Avtomobilska industrija, letalstvo, promet in logistika, industrija prostega časa, sanitarije, gradnja čolnov, avtomatizacija Razpoložljivost: januar 2026 Model: 5-osni CNC rezkalni stroj RT-F 1400 Podatki o vretenu: 8 kW / 6,4 Nm; 1000-36000 1/min; HSK E 40 Hitri pomik X/Y/Z: 40/40/30 Mere obdelovanca X/Y/Z: 1000 x 800 x 400 Krmiljenje: Fanuc z IPC, ročni terminal HMOP Type B Menjalec orodij: 12 orodij Mize: 1 okrogla miza Vakuumski sistem: da Preverjanje poloma orodja in dolžine: Renishaw-TS 27 R Ostalo: zbiralnik za odrezke, pohodno perforirano pločevino, pločevina za odsesavanje na zadnji strani Leto izdelave: 2026 Stanje: novo

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2008, proizvajalec krmilnikov: SIEMENS, model krmilnika: Sinumerik, skupna višina: 2.800 mm, skupna masa: 20.000 kg, največja hitrost vretena: 16.000 obr/min, moč vretenovega motorja: 28.000 W, teža orodja: 6.000 g, This 3-axis SAMAG MFZ 2-3 was manufactured in 2008. It features a working area of 300 x 500 x 450 mm, rapid traverse speeds up to 60 m/min, and a tool magazine with 90 positions. The spindle supports a speed range from 50 to 16,000 rpm with a drive power of 28 kW. Ideal for high precision and efficiency in machining tasks. Contact us for further information on this machine. Machine Advantages Technical Machine Advantages • Required installation space (length x width): approx. 5950 mm x 6700 mm • Weight (kg) including coolant system and chip conveyor: approx. 25,000 kg • Operating voltage: 400 V 3~ 50 Hz • Control/valve voltage: 24 V DC • Machine power rating: approx. 82 kVA • Main switch pre-fusing: 3 x 160 A • Connector cross section: 70 mm² Rbsdpfx Aex Nr Ilod Tet Additional Information Ott tool clamping system Torque (S1/S6): 63/83 Nm Rated speed: 4200 rpm Spindle bearing diameter: 70 mm Spindle lubrication: Lifetime grease lubrication 1 horizontal 180° swivel support (W axis) Faceplate diameter (NC drive/counter bearing): 500/345 mm Permissible tangential torque: 15,000 Nm Positioning accuracy: ±3 arcseconds Swivel time (0°/180°): Approx. 6 s Number of horizontal 360° workpiece support axes Positioning via face gearing: 120 x 3° Positioning accuracy (120 x 3°): ±3 arcseconds Max. transport load per A axis: approx. 600 kg Permissible tangential torque: 5000 Nm Work area (interference circle x length): Ø700 x 940 (1036) mm Positioning at intermediate positions outside the 3° division: Possible (NC position control) Positioning accuracy: ±25 arcseconds Permissible tangential torque: 1000 Nm Tool magazine: 90 tool positions (3 x 30) Max. tool diameter with free adjacent positions: 160 mm Chip-to-chip time (within 1 cassette): Approx. 5.2 s Media Hydraulic unit capacity: 160 l Max. operating pressure: 160 bar Max. flow rate: 12 l/min Pneumatic system: required compressed air connection, required air consumption (short-term) 6 ± 0.5 bar Plant air quality: Class 545 according to DIN-ISO 8573-1 Coolant system: Knoll coolant unit with coolant cooling Coolant tank capacity: Max. 1400 l Separate machine bed flushing: 160 l/min at 2.6 bar External tool cooling and various flushing functions: 120 l/min at 3.5 bar Internal tool cooling through the spindle: 40 l/min at 60 bar Dimensions Machine depth 5450 mm

Stanje: dober (rabljeno), Leto izdelave: 2013, obratovalne ure: 37.297 h, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 3.400 mm, pomik osi Y: 2.300 mm, pomik po osi Z: 1.000 mm, hitro pomikanje X-os: 60 m/min, hitri pomik os Y: 60 m/min, hitri pomik na osi Z: 40 m/min, proizvajalec krmilnikov: Siemens, model krmilnika: 840D sl, širina mize: 1.500 mm, višina mize: 30 mm, dolžina mize: 2.000 mm, obremenitev mize: 2.000 kg, največja hitrost vretena: 18.000 obr/min, delovne ure vretena: 12.486 h, moč vretenovega motorja: 24 W, število mest v zalogovniku orodij: 21, Oprema: dokumentacija / priročnik, vrtilna hitrost brezstopenjsko nastavljiva, For sale is an EiMa CNC-controlled 5-axis machining center, Type Sigma M, featuring a fixed gantry and a traversing table, designed for precision machining of aluminum and finishing operations in steel. The machine was developed for high accuracy, rigidity, and large travel ranges, making it ideally suited for demanding milling, drilling, and sawing tasks in the metal and aluminum profile sector. Year of manufacture: 2013 Power-on hours: approx. 37,297 h (as of November 2025) Spindle runtime: approx. 12,486 h total (as of November 2025) AXIS TRAVELS & DYNAMICS: - X 3,400 mm · Y 2,300 mm · Z 1,000 mm - Feedrates: X/Y 60 m/min, Z 40 m/min STRUCTURE & TABLE: - Heavy-duty steel frame, precision linear guides, servo drives, automatic central lubrication - Traversing table 2,000 × 1,500 mm, 30 mm thick, threaded grid 100×100 mm - Max. table load 2,000 kg SPINDLE & TOOL CHANGER: - 24 kW HSK 63 A spindle, up to 18,000 rpm, water-cooled - Disc-type tool changer with 20 positions + 1 pick-up station (for tools up to Ø 500 mm) 5-AXIS HEAD: - C3 fork-type head, swivel ranges approx. C ±200°, A ±120°, high positioning accuracy MEASUREMENT TECHNOLOGY: - m&h wireless probe (workpiece measurement) - BLUM laser (tool measurement) EQUIPMENT: - MMS unit (internal & external lubrication) - Full enclosure, separate tool change chamber - Mist extraction with electrostatic separator (approx. 1,900 m³/h) already integrated CONTROL: - Siemens 840D sl, 5-axis package, Advanced Surface, TCP - 15" operator panel, remote maintenance ready Rbedpfox H Ib Nsx Ad Tst ACCURACY: - Repeat accuracy approx. ±0.012 mm SPECIAL FEATURES: - Machine under power – demonstration possible at any time - Direct from production – not a dealer sale - Complete technical documentation available - Support with dismantling, loading and transport possible (at extra charge) HIGHLIGHT: - New replacement spindle from Omlat included (value approx. €25,000) NOTE: - Collection possible only in January/February All details provided to the best of our knowledge. Subject to change, error, and prior sale.

Stanje: rabljeno, Leto izdelave: 1997, Hodi X 600 – Y 400 - Z 350 Vreteno obrati 20.000 Redpfxex E T Rgj Ad Tebt Držalo BT 40 Big Plus Število orodij: 30 CNC Fanuc Miza s 4. osjo Sistem za megljenje z oljno meglico

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2008, proizvajalec krmilnikov: MAKINO, model krmilnika: Pro5, obremenitev mize: 1.200 kg, teža orodja: 20.000 g, število osi: 4, This 4-axis horizontal machining center Makino a81 was manufactured in 2008. It offers robust capabilities for precision machining. Consider the opportunity to purchase this Makino a81 horizontal machining center. Contact us for further information. Additional Equipment • Spindle cooling • Tank unit with Knoll compact band filter, 3200 liters • Coolant supply through the spindle • Oil mist extraction • Scraper belt conveyor • Retrofit kit for stand-alone operation (currently used as a system machine) Machine Advantages Technical Advantages • Cross travel (X-axis) of the column: 900 mm • Vertical adjustment (Y-axis) of the spindle unit: 800 mm • Longitudinal travel (Z-axis) of the table: 1020 mm • Permissible swing diameter in the working area: 1000 mm • Max. swivel height from the pallet surface: 1300 mm • Pallet size: 630 x 630 mm • Pallet NC rotary table with 4th NC axis • Input resolution: 0.001° Rbsdpfx Adjx D Ngxj Tjt • Positioning accuracy: ± 3 arcseconds • Tool magazine with 242 storage spaces Additional Information Power Supply 400 V, 3-phase AC, 50 Hz Rated power: 72 kVA Control System Options for 48 zero points and custom Macro B Tool life monitoring Tool breakage detection Adaptive feed control Compressed air through the spindle Knoll compact band filter, 3200 liters Magnetic separator Dual-switching filter for high-pressure coolant (IKZ) Coolant supply through the spindle Compressed air through the spindle Oil mist extraction Scraper belt conveyor Control system: Makino Pro5 Options for 48 zero points and custom Macro B Tool life monitoring Tool breakage detection (parallel to main operation) Adaptive feed control Retrofit kit for stand-alone operation (currently used as a system machine (FFS/FMS)) Pallet changer with accommodation for 2 pallets in alternating operation on a station positioned outside the work area Pallet holder rotatable, indexed in 90° steps, 0-position electronically monitored Coding for automatic program call-up when the pallet is inserted Pallet storage space secured with protective device and electric interlock

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2011, proizvajalec krmilnikov: SIEMENS, največja hitrost vretena: 10.000 obr/min, moč vretenovega motorja: 17.000 W, število osi: 3, This 3-axis HELLER MC 2000 was manufactured in 2011 and features a robust three-phase motor spindle delivering 17 kW at 10,000 rpm, equipped with an SK 40 tool holder. It comes with a 2-axis servo tool changer, a stationary tool magazine with 54 slots, and a pallet changer with 2 pallet positions. If you are looking for a high-quality milling machine, you should consider the HELLER MC 2000 we have for sale. Please contact us for further information about this machine. Additional Equipment • Scraper belt conveyor for dry machining • Cold light in the working area • Central cooling unit for motor spindle and control cabinet, CFC-free Machine Advantages Technical Advantages • Central cooling unit for motor spindle and control cabinet, CFC-free • Built according to CE standards • Paint finish: grey-white / anthracite grey / dust grey / HELLER red • Control cabinet with integrated control, regulation, and power sections • Operating voltage 400V / 50Hz, voltage tolerance +/- 10% // control voltage 24V DC • Increased spindle output with power cutting at 240 Nm • Dynamic axis performance • Fully enclosed machine, including covers • Automatic central lubrication • Hydraulic system Further Information The operating manual includes: • Operating instructions • Control-specific documents • Maintenance instructions • List of spare and wear parts • Supplier instructions • Fluid diagrams and electrical circuit diagrams Three-phase motor spindle package with hollow shaft motor, 17 kW at 40% duty cycle, 10,000 rpm asynchronous, SK 40 tool holder according to DIN 69871, Form A, AD, and B, for pull studs according to DIN 69872 Form A and B Adjustable, maintenance-free AC feed drives Direct distance measuring system on the X, Y, Z, and B axes Travel Range 2-axis servo tool changer Stationary tool magazine with 54 tool holders and fixed-position encoding Operator panel at workpiece setup station NC rotary table with 360,000 x 0.001° incrementation Pallet changer with 2 pallet positions Workpiece Rjdpfx Asx D Nbpjd Tjbt Setup station, manually rotatable 4 x 90° The machine has been measured.

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2010, obratovalne ure: 29.000 h, proizvajalec krmilnikov: SIEMENS, model krmilnika: 840 D, največja hitrost vretena: 12.000 obr/min, Gre za sistem, ki ga sestavljata HELLER MCH 350 in HELLER MCH 350 C z 22-paletskim sistemom s paletami velikosti 800x800 mm. Obe modela imata 70-barni tlačni sistem; MCH 350 doseže do 12.000 vrt/min, MCH 350 C pa do 8.000 vrt/min. Izkoristite priložnost za nakup tega horizontalnega obdelovalnega centra HELLER MCH 350 + MCH 350 C. Za več informacij o tem sistemu nas kontaktirajte. Dodatna oprema • Palete: 22 kosov velikosti 800x800 mm Prednosti stroja Tehnične prednosti stroja: Rbsdpfxjx D Skmj Ad Tot • Tlak: 70 barov pri obeh strojih • Orodni sistemi: 2 x 234 hsc 100 • MCH 350 C = 8.000 vrt/min Dodatne informacije Obratovalne ure MCH 350: 29.000 ur Obratovalne ure MCH 350 C: 22.105 ur

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2018, Funkcionalnost: popolnoma funkcionalen, premer žaginega lista: 600 mm, TE KOOP — Soenen Hendrik CNC-bewerkingslijn voor aluminium raam- en deurprofielen Een volledig operationele Soenen Hendrik CNC-bewerkingslijn voor aluminium, direct inzetbaar en te bezichtigen tijdens productie. Te koop wegens vervanging door een intern ontwikkeld CNC-systeem. Belangrijkste kenmerken ✔ Volledig werkend, op afspraak te bezichtigen tijdens productie ✔ Geautomatiseerde profielaanvoer en -afvoer ✔ Tot 20 profielen verwerken zonder handmatige tussenkomst ✔ 18 freesspindels: - 5 boven- en onderfrezen (waarvan 1 in hoekverstelling) - 4 voor- en achterspindels ✔ 600 mm afkortzaag met instelbare verstekhoek (22°–158°) ✔ Sleufunit – ideaal voor T-profielen, stijlen, enz. ✔ Automatische etikettering van afgewerkte profielen Rodpfxsx Dcnpo Ad Tsbt ✔ Compatibel met UniLink voor machinebesturing ✔ Afvoerband voor reststukken/afval ✔ Inclusief UPS noodstroomvoorziening ✔ Geïntegreerde camerasystemen Deze machine biedt een uitstekende oplossing voor fabrikanten die op zoek zijn naar een volledig geautomatiseerde CNC-bewerkingslijn met hoge verwerkingscapaciteit en minimale operatorinzet. Neem contact met ons op voor prijsinformatie, bezichtiging of aanvullende technische gegevens.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2000, obratovalne ure: 59.458 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 1926, potovalna razdalja osi X: 3.500 mm, pomik osi Y: 2.500 mm, pomik po osi Z: 1.250 mm, širina mize: 1.800 mm, dolžina mize: 2.200 mm, obremenitev mize: 15.000 kg, skupna masa: 48.000 kg, hitrost vretena (min.): 5 obr/min, največja hitrost vretena: 2.500 obr/min, moč: 48 kW (65,26 KM), premer tulec: 130 mm, hod vretena: 630 mm, Oprema: kabina, vrtilna hitrost brezstopenjsko nastavljiva, Tehnične specifikacije Rodpfoxyu Dzjx Ad Tsbt Pomik po osi X: 3.500 mm Pomik po osi Y: 2.500 mm Pomik po osi Z: 1.250 mm Velikost mize: 1.800 × 2.200 mm Nosilnost mize: 15.000 kg Največja hitrost vretena: 2.500 obr/min Premer vretena: 130 mm Krmiljenje: HEIDENHAIN TNC 426 Število osi: 5 Avtomatski menjalec orodij: 60 pozicij Vpenjanje orodja: ISO 50 Obratovalne ure Čas delovanja stroja: 59.458 h Obratovalni čas vretena: 23.258 h Oprema in lastnosti Kabina za operaterja Popolna dokumentacija stroja priložena

Stanje: potreben popravila (rabljeno), Leto izdelave: 2008, Funkcionalnost: nefunkcionalno, številka stroja/vozila: B-7969, Caracteristici tehnice: - Suprafață de prelucrare: X 800 mm; Y 400 mm; Înălțime de la suprafața mesei la sol: 850 mm (sarcină maximă 450 kg) - Număr canale T: 3 / Distanța între canalele T: 125 mm / Lățimea canalelor: 18 mm - Descriere axe: 3 AXE LINIARE (X, Y, Z) / a 4-a axă - Viteză de avans rapid: X, Y, Z - 30 m/min - Cursă de lucru: Cursă longitudinală (axa X) 600 mm, Cursă transversală (axa Y) 400 mm, Cursă verticală (axa Z) 510 mm Capacități cap arbore: - Distanța maximă ax arbore-masă: 650 mm - Priză arbore: ISO7388 (cu răcire internă), Portsculă (dimensiunea 40) - Plajă turații (standard): 100/14000 rpm, Cuplu maxim / la 330 rpm: 63,7/89,4 Nm Schimbător automat de scule: - Număr scule: 20, Sistem de selectare: Secvențial / aleator, Diametru maxim (sculă adiacentă): 85 mm, Diametru maxim (sculă neadiacentă): 135 mm, Lungime maximă sculă: 300 mm, Greutate maximă sculă: 6,5 kg - Timp schimbare sculă: 3 sec Racord electric: - Tensiune: 3x400V/50Hz - Putere instalată: aprox. 30 kVA Dimensiuni: - suprafață ocupată: aprox. L 2,1 x l 3,5 x H 3 m - greutate: aprox. 4200 kg Echipare: - CNC Fanuc Series 31i MODEL A - Extractor șpan - Sistem de ungere - Panou electric cu sistem de răcire - Sistem răcire arbore principal Rodpfx Aexxvtued Tsbt - Documentație: Electronic disponibilă / Carte nu este disponibilă Stare utilaj: NEFUNCȚIONAL - a 4-a axă defectă (reparabilă) - demontată de pe utilaj - schimbătorul de scule defect (reparabil) - demontat de pe utilaj - pompă hidraulică defectă - necesită înlocuire completă
