Koordinatni merilni stroj

Zeiss Prismo

Stanje: pripravljen za uporabo (rabljen), Zeiss 608093 9203 ÄZ02 35/05 meritev poti 32 Prismo / meritev položaja 32 Prismo-ST 608093-9203-701, rabljeno, kot novo, 100% delujoče Iaodpey T Dp Aefx Abxou

Stanje: rabljeno, Leto izdelave: 2023, Stružnice Pomik X: 495 mm Pomik Y: 125 mm Pomik Z: 1560 mm Dolžina struženja: 1540 mm Maks. obhodni premer: 660 mm Maks. premer struženja: 660 mm Vreteninska izvrtina: 65 mm Območje vrtljajev do: 5000 obr/min Iajdey Nxc Ajpfx Abxeu Pogonska vretena B-os: ±120° Orodno vreteno: 12.000 obr/min Magazin: 38 orodij Teža: 18.800 kg Stanje: skoraj nerabljen, kot nov

Stanje: rabljeno, Rabljena 3D CNC koordinatno-merilna naprava. ZEISS Prismo 7 – leta 2016 posodobljena z UCC krmiljenjem, PH10M rotacijsko-nagibnim sistemom, joystick kontrolno enoto, SP25 skenirno tipalo in računalnikom s 3D programsko opremo RationaDMIS. Dodatne podrobnosti na zahtevo. Merilno območje: Iodpfx Aoy Nzk Ajbxoau X = 900 mm - Y = 1200 mm - Z = 700 mm Cena: na zahtevo > Zahtevajte našo podrobno ponudbo. Seveda nudimo vse storitve, kot so montaža, vzdrževanje, servis, usposabljanje, priprava programov itd.

Stanje: zelo dobro (rabljeno), Leto izdelave: 1999, Funkcionalnost: popolnoma funkcionalen, merilno območje os X: 700 mm, merilno območje osi Y: 900 mm, merilno območje os Z: 500 mm, Zeiss CNC Coordinate Measuring Machine Prismo MP5 Year of manufacture: 08/1999 Last calibration: 09/2023 Measuring range: X = 700 mm, Y = 900 mm, Z = 500 mm Iasdpoufgbnjfx Abxsu Machine features, equipment: C98 control with operator panel RDS sensor technology with RST 5-position probe change magazine RST 5x probing system Reference probe Probe accessories Calibration sphere PC with monitor Software: Calypso Basic 5.4 Loading system Further accessories and options available Complete retrofit to C99 and latest Calypso version possible Available at short notice

Stanje: dober (rabljeno), Leto izdelave: 2012, Funkcionalnost: popolnoma funkcionalen, merilno območje os X: 400 mm, merilno območje osi Y: 400 mm, merilno območje os Z: 200 mm, potovalna razdalja osi X: 400 mm, pomik osi Y: 400 mm, pomik po osi Z: 200 mm, vhodna napetost: 230 V, Oprema: Na voljo je tipska ploščica, osvetlitev, Year of manufacture: 2012 Tactile probe: Vast XXT E0 X/Y (1D) in [μm] at 20 ±2 °C: 1.7 + L/250 E0 XY (2D) in [μm] at 20 ±2 °C: 1.7 + L/250 Iaedpfxsuq Nfhs Abxju E0 (3D) in [μm] at 20 ±2 °C: 1.9 + L/250 Scanning probing deviation MPE according to ISO 10360-4:2000 THP: 2.7 [μm] Single stylus probing deviation, form MPE according to ISO 10360-5:2010 PFTU: 1.9 [μm] Camera system: Zeiss Discovery 12 EB X/Y (1D) 5) in [μm] at 20 ±2 °C: 1.7 + L/250 EB XY (2D) 5) in [μm] at 20 ±2 °C: 1.7 + L/250 Probing deviation MPE according to ISO 10360-7:2011 PF2D 5): 1.7 [μm] Probing deviation of the image processing system MPE according to ISO 10360-7:2011 PFV2D 5): 1.2 [μm] Available services: Delivery, commissioning

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 1999, Funkcionalnost: popolnoma funkcionalen, merilno območje os X: 900 mm, merilno območje osi Y: 1.200 mm, merilno območje os Z: 700 mm, model krmilnika: C98 mit Bedienpult, Stroj je bil leta 2019 posodobljen ter opremljen z novim računalnikom s programsko opremo Calypso in tipalo VAST Gold! Zadnja kalibracija je bila opravljena junija 2021! TEHNIČNI PODATKI Merilno območje X-os: 900 mm Merilno območje Y-os: 1.200 mm Merilno območje Z-os: 700 mm PODROBNOSTI O STROJU Krmiljenje: C98 z upravljalno konzolo OPREMA Tipalo VAST Gold 7-mestni magazin za zamenjavo tipal Menjalni krožnik za tipala Dodatki za tipala Iajdpfx Aboya Hfxoxsu Kalibracijska krogla Tehnična dokumentacija Delovna postaja z monitorjem Programska oprema Calypso Basic

Leto izdelave: 2000, stanje: rabljeno, x-travel 1000 mm y-travel 1600 mm z-travel 800 mm Control system: WENZEL WPC 2040/FW31.351 Total power requirement: kW Machine weight approx. 5500 kg Required space approx. m WENZEL CNC-controlled vertical 3-D coordinate measuring machine Model: LH 108 CNC Year of manufacture: 2000 (continuously serviced and calibrated by manufacturer) Y-axis as longitudinally movable measuring portal: 1,600 mm X-axis as transverse measuring head carriage: 1,000 mm Z-axis as vertical measuring spindle: approx. 800 mm Max. workpiece weight / table load: approx. 2,250 kg Clearance under measuring portal: approx. 900/1000 mm Overall table size: approx. 2,600 x 1,250 mm Table height above floor: approx. 700 mm Table plate thickness: 380 mm Machine height: approx. 3,100 mm Weight: approx. 5,500 kg Iaodpjt Hw Nysfx Abxju Special Equipment / Accessories: • Measuring table, crossbeam, and spindle made of dark natural hard stone; table with 6 x 9 threaded holes for securing workpieces/fixtures • All axes are air-bearing, making them easy to operate, virtually wear-free, and equipped with incremental linear scales with a resolution of 0.0005 mm • WENZEL CNC control unit Type WPC 2040 / FW31.351 built into the workstation (Control system was replaced approx. 3 years ago) • WENZEL measuring software Type METROSOFT QUARTIS R 12 SP 1 with SurfPro package and QUARTIS Q-DAS • RENISHAW motorized rotary and swivel head (automatic indexing in 7.5° steps) with measuring probe Model PH 10 M Plus and measuring probe TP 20 plus various probe accessories • RENISHAW Probe Head Controller Type PHC 10 C-3 Plus, also integrated into the workstation • Automatic probe change possible, 6-position probe magazine Model MCR 20 mounted on the table • Mobile hand control panel with progressive control lever (joystick) for manual adjustment of all 3 axes with continuously adjustable travel speeds • Reference sphere for setup on the table, workstation, various clamping devices, etc. Condition: Very good – can be inspected under power in stock, ready for demonstration, was professionally disassembled by a measuring machine specialist at previous owner and reassembled at current location. Delivery: Ex stock – as is and as inspected Payment: Net – upon receipt of invoice.

Stanje: novo, Leto izdelave: 2021, Funkcionalnost: popolnoma funkcionalen, Stock machine "NEW" – available at short notice! (Subject to prior sale) CNC Control: Fanuc 0i-MF Plus, 10.4" with Manual Guide i & 2 MB NC memory LOOK-AHEAD function, 400 blocks Machine table: Table size: 950 x 550 mm Table load capacity: 800 kg T-slot width: 18 mm Number of T-slots: 3 T-slot distance: 150 mm Traverse ranges: Travel paths X/Y/Z: 860/550/550 mm Spindle nose to table surface: 150 - 700 mm Linear guides & speeds: Ball guides in X/Y axis Roller guides in Z axis Rapid traverse X/Y/Z: 40/40/30 m/min Feed rate for milling: 0 – 10,000 mm/min Minimum increment: 0.001 mm Tool magazine (CAM type) / changer: Number of magazine positions: 30 System: random Max. tool diameter: Ø75 mm Max. tool diameter with free adjacent slots: Ø150 mm (40 tools: Ø130 mm) Max. tool length: 300 mm Max. tool weight: 7 kg Spindle: Spindle taper: SK-40 Drive power (30min/contin.): 18.5/11 kW 15,000 rpm direct-drive spindle Spindle oil cooler Coolant, chip, and compressed air management: Coolant unit including 300-liter tank and pumps External coolant around the spindle Chip augers right and left in machine bed Compressed air nozzle at spindle (M32/M33) Compressed air through spindle (M38/M39) Compressed air and coolant gun Other features: Swiveling operating panel Electronic handwheel (wired) Central oil/air lubrication Fully enclosed guard Worklight Heat exchanger on electrical cabinet Auto-power OFF function Hand tool set Signal lamp Transformer 400 VAC, 50 Hz CE Declaration of Conformity per European guidelines Electrical and pneumatic requirements: Electrical connection: 36 kVA Required pneumatic supply pressure: 6 bar Dimensions: Machine size: W2,260 x D2,900 x H2,775 mm Required footprint: W3,160 x D3,000 x H3,000 mm (includes chip conveyor discharge to the left) Net machine weight: approx. 5,400 kg Available special equipment: Spindle: - Direct-driven spindle SK-40, 15,000 rpm - Drive power (30min/contin.): 18.5/15 kW (FANUC motor) Tool magazine / changer: - Drum tool magazine with 30 positions, DIN69871, SK-40 Rotary or additional axes: - Preparation for 4th axis (FANUC control), incl. cabling and Harting connector, without axis drive Coolant, chip, and compressed air management: - Bed flushing - ICS high-pressure coolant pump, 20 bar, for direct-drive spindles - Including cartridge filter - Belt-type chip conveyor with chip cart (discharge at front to left side of machine) Measuring and monitoring systems: - RENISHAW OMP-60 probe with infrared transmission system for workpiece measuring, incl. probe holder, repeatability: 1μm - RENISHAW NC4+ laser tool measurement system and tool breakage control in machine, incl. bracket - Auto-door (side door) - Pneumatic interface for workpiece clamping - Clamping devices as shown With RoboJob Mill Assist 25kg (Year 2025 – NEW) - Fully enclosed - Double gripper Available immediately Iedjifn N Nspfx Abxeau

Stanje: zelo dobro (rabljeno), Leto izdelave: 2014, Funkcionalnost: popolnoma funkcionalen, merilno območje os X: 1.200 mm, merilno območje osi Y: 2.000 mm, merilno območje os Z: 1.000 mm, Measuring ranges X-axis: 1200 mm Y-axis: 2000 mm Z-axis: 1000 mm Length measurement uncertainty ISO 10360 E = [2.6 + 4L/1000] µm CNC control: Renishaw UCC S5 Handheld terminal: Renishaw MCU-5, optionally wireless MCU-5W Temperature sensors: Renishaw Probe system: Renishaw REVO-2 5-axis scanning system Iasdpfxjdv I Abs Abxju Probe change system: Renishaw (Price REVO approx. €80,000 new) Software: Inspect3D Inca V6 new license (all languages) Original year of construction: 2014, modernized in 2017 and 2025 Exchange for another CMM possible

Stanje: generalkompletno obnovljen (rabljeno), Measuring ranges X/Y/Z = 900 x 1200 x 850 mm Measurement uncertainty 4.0 + 4.5L/1000 (in original condition, currently significantly improved after modernization) Fully modernized in 2018 with Pantec Controller Eagle Pro Probe system: Renishaw PH10MQ with SP25M Completely new software: Inca Premium (other software options available upon request) HP Workstation PC Optional: Iaedpfx Absdpak Rexou Laser scanner (e.g. Kreon) Probe changer Rotary table, etc.
