Laserski stroj za rezanje

YAWEI HLF1530 4KW

Leto izdelave: 2010, stanje: rabljeno, METAL SHEET ROLL FORMING LINE FOR TILE PANELS ILKWANG Bledsymbfyopfx Aa Rei Reduced price for urgent sale Scope of supply: 1. Decoiler 2. Front shear + coil guiding table 3. Film applicator 4. Base parts of cassette-type roll forming machine 5. Roll forming machine for “COPPO” type tile 6. Roll forming machine for “ATIIKA” type tile 7. Roll forming machine for “T177.5” type tile 8. Shearing (cutting) machine: flying cut-off type 9. Stretching section 10. Automatic stacker 11. Electrical control panel Technical specifications: - Manufacturer: IL Kwang (Korea) - Year of manufacture: 2010 - Material: Pre-painted galvanized steel sheet (ASTM A 526 / JIS G 3302 SGCC) - Tensile strength: 250 ~ 320 MPa - Maximum coil width: 1250 mm - Coil thickness: 0.35 – 0.8 mm - Maximum coil weight: 15 tons - Maximum outer coil diameter: 1300 mm - Coil inner diameter: 508 mm - Line speed (length > 5 m): Max. 8 m/min - Speed control: Frequency control by inverter - Main voltage: 380 / 50 V/Hz 3 Phase - Dimensions (L x W x H): Approx. 30 x 8 x 5 m Component manufacturers: - Motor: Siemens (ICE type) - PLC + Inverter: Siemens 7 - Servo: Mitsubishi (with C.E.) - Touch screen: Pro-face (with C.E.) - Electrical components: L.G (with C.E.) Main voltage: 380 / 50 V/Hz 3 Phase Line speed (length > 5 m): Max. 8 m/min Material: Pre-painted galvanized steel sheet (ASTM A 526 / JIS G 3302 SGCC) Tensile strength: 250 ~ 320 MPa Maximum coil width: 1250 mm Coil thickness: 0.35 – 0.8 mm Maximum coil weight: 15 t Maximum outer coil diameter: 1300 mm Motor: Siemens (ICE type) PLC + Inverter: Siemens 7 Servo: Mitsubishi (with C.E.) Touch screen: Pro-face (with C.E.) Electrical components: L.G (with C.E.) Speed control: Frequency control by inverter Coil inner diameter: 508 mm Dimensions (L x W x H): Approx. 30 x 8 x 5 m

Stanje: rabljeno, Leto izdelave: 2017, Obratovalne ure laserja vklopljen: 28.313 h Obratovalne ure žarka vklopljen: 8.421 h Moč laserja: 6000 W Delovno območje laserskega delovanja: 3048 x 1524 x 70 mm Največja debelina konstrukcijskega jekla: 25 mm Bsdjyrfxzepfx Aa Rjli Največja debelina nerjavečega jekla: 30 mm Največja debelina aluminija: 30 mm Največja debelina bakra: 12 mm Največja debelina medenine: 12 mm Dolžina: 11.000 mm Širina: 6.050 mm Višina: 2.565 mm Teža stroja: 12.000 kg Skupna priključna moč: 31 kW Standardna oprema: - Največja hitrost pozicioniranja po oseh x, y: 120 m/min - Največja simultana hitrost pozicioniranja: 170 m/min - Pozicijska odstopanja Pa: +/- 0,05 mm - Razpon pozicijske natančnosti Ps: +/- 0,025 mm - Največja masa obdelovanca: 1.100 kg - Upravljanje preko panela: ByVision Touchscreen upravljanje in ročna upravljalna enota Dodatna oprema: - Menjalec šob, 40-kraten - Detection Eye - Cut Control - Power Cut Fiber Avtomatizacija: - ByTrans Extended

Stanje: delavnici obnovljeno (rabljeno), Funkcionalnost: popolnoma funkcionalen, LVD Press Brake 4000 x 200T Type: PPBL 200/40 Blsdpfx Aajwtmi Eo Roi Capacity: 4000 x 200T Maximum stroke: 150 mm Weight: 13.5T With mobile blade holder rack

Stanje: rabljeno, Leto izdelave: 1997, The press brake was manufactured in 1997 in England at the EDWARDS PEARSON factory. The bending press is in good condition and is being sold complete with tooling. It has always been serviced and maintained on schedule. The machine is connected and can be demonstrated or inspected on site. Specification: Model: EDWARDS PEARSON 100/3100 PR6 Year: 1997 Working length: 3,100 mm Bending force: 100 t Bsdpfx Aasrfx Uto Rsli Stroke: 172 mm Distance between table and frame: 450 mm Working speed: 100 mm/s Return speed: 110 mm/s Axes: auto X1, X2, Y1, Y2, Z1, Z2, R Tooling: Included Weight: 7 t Other: Newly replaced display, connected keyboard for easier operation. If you have any further questions, we will be happy to assist you.

Leto izdelave: 2000, stanje: dober (rabljeno), Press force: 28 t Bjdpfoi Eld Uox Aa Rjli X-axis: 2000 mm Y-axis: 1000 mm Machine weight approx.: 11,000 kg

Leto izdelave: 2007, stanje: dober (rabljeno), Rabljeni Bystronic Byspeed CNC laserski stroj 4,4 kW naprodaj Rabljeni Bystronic laserski stroji 4,4 kW naprodaj VIDEO SPODAJ: Byspeed 3015 4,4 kW Bljdpfx Aasgwa Swe Rei Leto izdelave/namestitve: 2007 Proizvajalec: Bystronic Model: Byspeed 3015 Velikost pločevine: 3 metre x 1,5 metra / 3000 mm x 1500 mm Moč laserja: 4,4 kW / 4400 W Krmiljenje: ByVision CNC02 Avtomatizacija: ni na voljo Leto: 2007 Stanje: dobro delujoče, servisirano od novega Byspeed 3015 4400 W Marec 2010 Obratovalne ure: 44.189 h Ure rezanja: 20.490 h Stroj je v dobrem stanju, ves čas pod rednim servisom Bystronic UK. Vključene možnosti: Bypos avtomatsko ostrenje CutControl 2 rezalni glavi Orodja in dodatna oprema Torit odsesovalec prahu Dostava, montaža in usposabljanje možni z doplačilom.

Stanje: novo, Leto izdelave: 2025, BODOR laser cutting systems in top quality at top prices. - Easy programming – including service and training, installation and commissioning. - Machines available with 3 kW to 30 kW power Bedpfx Aaefbg Hbe Reli User-friendly and suitable for both beginners and established companies.

Stanje: dober (rabljeno), Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 2011, obratovalne ure: 31.411 h, TRUMPF Trumatic 3000 K03 Punch-Laser Combination Machine This punch-laser combination machine allows the flexibility of laser cutting to be combined with the advantages of punching. The simultaneous application of these two cutting technologies opens up numerous new possibilities: even complex sheet metal components can be produced. Technical Data - Punching force: 165 kN - Maximum sheet size (X, Y): 2500 mm x 1250 mm - Maximum sheet thickness: 3 mm - Maximum tool diameter: 76.2 mm - Maximum forming height: 25 mm - Maximum bending length: 55 mm - Chipless thread forming: M2.5 to M8 - Laser power: 2000 W - Number of tool stations: 18 - Tool change time (per tool): 3.9 s - Tool change time (for MultiTool): 2.2 s Bjdjycuypepfx Aa Roli - Positional accuracy: ± 0.1 mm - Repeat accuracy: ±0.03 mm For optimum surface quality of the sheet metal components, the machine is equipped with a brush table and rollers around the forming tools. The MultiTool tool holders can accommodate up to 180 different forming tools. Thanks to shorter production cycles and lower energy consumption, the laser-punch combination machine enables lower part costs compared to flatbed laser cutting systems, ensuring greater economic efficiency. This equipment is ideal for the efficient, high-volume production of complex sheet metal parts. The laser cutting head allows for the cutting of intricate shapes, creates high-quality edges, and can be used when the required profile punching tool is not available.

Stanje: rabljeno, Leto izdelave: 2013, Punching force 220 kN Laser power in watts 4000 Travelling distance - x 2500 mm Travelling distance - y 1250 mm Cutting capacity in mild steel 8 mm Cutting capacity in stainless steel 8 mm Cutting capacity in aluminium 6 mm Workpiece weight 280 kg Machine weight approx. 24,000 kg Dimensions 10130 x 8898 x 2328 mm Bodpfxjy D T S Uj Aa Rsli Including DORNER 2200 series conveyor belt Operating hours: - approx. 7,880 h Standard equipment: - Ball transfer tables (traveling with processing head) - Linear magazine for tool stations and clamps - 22 tool stations, 3 clamps - Foot switch for clamp activation - Trap door for punched parts 500 x 500 mm incl. sensor - Scrap bin - 2 finished parts bins (for punching and laser side) - Initial fill of hydraulic oil - FocusLine - NitroLine - FastLine - Additional Xp and Yp axes - Knock-out cylinder for laser parts - Fast trap door for laser parts 500 x 500 mm incl. sensor - Liftable laser cutting support - Slag cone detection TRUMPF Laser: - CO2 laser TruFlow 2700 incl. LensLine and optimized StandBy - Maintenance-free turbo radial fan - High-frequency excitation - Laser control TASC Cutting head: - Lens cutting head with 170 mm lens - Universal quick-change device (UTI) with bus connection - ControlLine Punching head: - Electro-hydraulic punching head - Hydraulic single-tool receptacle with 360° rotation - Programmable stripper (active/passive/follow-up) - Tool length compensation - Spray lubrication for punch - Punch slug extraction - Level monitoring for thread forming and tool lubrication Control: - Open control based on Rexroth IndraMotion MTX - 15" TFT colour display - Remote teleservice via Internet - Auto shut-off - Production plan Data transfer: - USB interface - RJ45 network connection Safety: - CE marking - Dual-beam light barriers - Hydraulic quick cut-off - Deflection detection - Full level calculation in the punching console Programming: - Advanced workshop programming Additional equipment: - Additional cutting head with 130 mm focal length - 1 MultiTool function - 1 MultiShear function - 1 Thread forming function incl. thread counter - 1 Marking/quick beading function

Leto izdelave: 2010, stanje: pripravljen za uporabo (rabljen), Na prodaj je CNC laserski rezalni stroj proizvajalca TRUMPF. Moč laserja: približno 3000 W (3 kW), delovno območje: X/Y/Z 3000 mm/1500 mm/115 mm. Poleg tega je na voljo ustrezen Liftmaster iz leta 2015, ki ga je mogoče kupiti tudi ločeno. Bledpfx Aajxxa Uco Rei
