CNC laserski

Trumpf 5030 FIBER

Stanje: dober (rabljeno), Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 2017, Tip: TruLaser 5030 fiber (L68); Leto: 09-2017; Delovno območje: 3000 x 1500 x 115 mm; Nazivna moč laserja: 8000 W; Guedpfx Asxlr R Noh Djh Krmiljenje: Siemens Sinumerik 840D SL; Delovne ure*: ca. 42.770/30.000 h; Maks. debelina pločevine/St: 25 mm; Maks. debelina pločevine/VA: 20/40 mm (z BrightLine fiber); Maks. debelina pločevine/Al: 20/25 mm (z BrightLine fiber); Največja hitrost: 265 m/min; Natančnost pozicioniranja: +/- 0,1 mm; Dolžina: 9229 mm; Širina: 6145 mm; Višina: 2200 mm; Teža: 9700 kg

Stanje: pripravljen za uporabo (rabljen), Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 2014, obratovalne ure: 26.000 h, potovalna razdalja osi X: 3.000 mm, pomik osi Y: 1.500 mm, pomik po osi Z: 115 mm, hitrost rezanja: 300.000 mm/min, teža obdelovanca (maks.): 1.800 kg, TEHNIČNI PODATKI Pomiki X-os: 3.000 mm Y-os: 1.500 mm Z-os: 115 mm Največja teža obdelovanca: 900 kg Laser TruDisk 5001 Maksimalna moč: 5.000 W Valovna dolžina: 1,03 µm Maksimalna debelina pločevine Ogljikovo jeklo: 25 mm Nerjaveče jeklo: 20/25 mm Aluminij: 20/25 mm Baker: 10 mm Medenina: 10 mm Hitrost Sočasno: 265 m/min Natančnost Pozicijska odstopanja Pa: 0,05 mm Povprečno pozicijsko razpršenje Ps max.: 0,03 mm PODATKI O STROJU Krmiljenje: Siemens Sinumerik 840D SL Dimenzije & teža Dimenzije (D x Š x V): 8.300 x 4.800 x 2.400 mm Gusdsxd Afhopfx Ah Dsh Teža: 12.000 kg Poraba energije Celotna enota: 7–39 kW Rezonator: 5 kW Fiber Ure vklopa žarka: 26.000 h Obratovalne ure: 68.000 h

Leto izdelave: 2013, obratovalne ure: 23.265 h, Stanje: pripravljen za uporabo (rabljen), Glavni pogon Moč laserja: 5000 W Obdelovanec Obdelovanec X: 3000 mm Obdelovanec Y: 1500 mm Gedpfx Asxaqmleh Douh Ta TRUMPF Trulaser 5030 Fiber je bila izdelana leta 2013. Ima zaprto ogrodje, navorni pogon, linearni direktni pogon in trdni laser TruDisk 3001. Opremljena je z avtomatskim menjalcem palet, 17-palčnim zaslonom na dotik in integrirano kamero za spremljanje procesa. Idealno za natančno lasersko rezanje z vlakni. Če iščete visokokakovostne možnosti rezanja, razmislite o stroju TRUMPF Trulaser 5030, ki je na voljo pri nas. Kontaktirajte nas za več informacij o tem stroju. Vrste uporabe Rezanje

Stanje: kot nova (razstavni stroj), Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 2018, obratovalne ure: 9.900 h, vrsta upravljanja: CNC krmiljenje, vrsta laserja: vlakenski laser, laserska moč: 8.000 W, leto zadnje generalne obnove: 2025, Oprema: CE označba, hladilna enota, menjalnik šob, nujno zaustavitev, odsesavanje prahu, varnostna svetlobna zapora, TruLaser 5030 fiber (L68) Standard equipment: Machine - Working area: 3000 x 1500 mm - Enclosed frame with integrated control cabinet - Automatic longitudinal pallet changer - Axis drive using linear motor technology and torque motor - Laser beam transmission by fiber optics - Machine cooling unit (water-to-air) - Integrated electrical cabinets with interior lighting - Single electrical switch for machine and laser - Longitudinal scrap conveyor - Work area lighting - Positioning laser diode - Oil misting device - PierceLine - FocusLine - NitroLine - PlasmaLine - Automatic nozzle cleaning - Transport and slinging device TRUMPF Laser - Fiber optic cable according to standard installation plan (laser source next to the machine) - Laser cooling unit (air-to-water) - Laser excitation by high-lifetime diode module - Laser power control Laser Cutting Head - Universal cutting head with adaptive lens system - "One cutting head" strategy - Cutting head protective window - Online monitoring of the protective window - ControlLine Gsdpsw Tza Refx Ah Djuh CNC - Sinumerik 840D SL CNC - Integrated technology data (Laser table) - 19" color touchscreen - Automatic shutdown - Programmable assist gas pressure - FastLine - FlyLine - AdjustLine - Internet teleservice - Easy Workshop Programming - Fast part reproduction - Copper cutting package (includes N2 and O2 cutting data) - Brass cutting package (includes N2 cutting data) - Microweld - Multi-sheet processing - Condition Guide Data Transmission - USB interface - RJ-45 network card - Central link Safety - CE certifications - Safety light barriers - Compartmentalized extraction device - Compact dust collector - Machine enclosure with certified protective windows (right-hand door) - Electric roof hatch Services - Commissioning - Machine network setup via teleservice Option: TruDisk 8001 solid-state laser (8 kW) with a single fiber output (BrightLine fiber, Smart Beam Control, Highspeed cutting package, and Performance Fusion cutting package included) - replaces TruDisk 3001. Smart Nozzle Automation (includes automatic nozzle changer, nozzle inspection, LensLine with automatic status monitoring, and SmartSkip) CoolLine Certified protective window on the left door Integrated camera 1 for process observation in the cutting area with networked image transmission (view over the first 2.5 m) Machine installation on the right Interface for LiftMaster Compact

Stanje: rabljeno, Leto izdelave: 2012, Laser operating hours: 51,942 h Beam-on hours: 29,734 h Laser power: 5,000 watt Control: Siemens 840 D Working area (laser operation): 3,000 x 1,500 x 115 mm Max. mild steel: 25 mm Max. stainless steel: 25 mm Max. aluminium: 25 mm Max. copper: 10 mm Max. brass: 10 mm Length: 9,950 mm Width: 4,600 mm Height: 2,400 mm Machine weight: 12,000 kg Standard Equipment: - Enclosed machine frame with integrated laser unit - Torque drive in combination with linear direct drives - Enclosed beam guidance via fiber optic cable - Machine cooling unit (water-air) - Integrated control cabinets with interior lighting - Automatic pallet changer (longitudinal direction) - Longitudinal conveyor belt - Work area lighting - Positioning laser diode - Spray device - PierceLine - FocusLine - NitroLine - PlasmaLine - Automatic nozzle cleaning TRUMPF Laser: - Solid-state laser TruDisk 3001 - Fiber optic cable as per standard layout - Laser cooling unit (water-air) - Excitation via pump diodes - Laser power control - Laser logbook function Cutting head: - Universal cutting unit with fully adaptive lens system - Protective glass against lens contamination - ControlLine: Height control and sheet edge detection Gedpfx Ahjwmynzs Djuh Control: - Simple and advanced workshop programming - Siemens Sinumerik 840D SL control - 17'' touch colour screen - Integrated technology data - Shut-off automation - FastLine - Quick reproduction - Teleservice Data Transfer: - USB interface - RJ-45 network connection Safety / CE Certification: - Light barriers - Multi-chamber extraction system - Integrated compact dust extraction unit - Machine enclosure, certified viewing window, right-side door - Electric roll-up roof Additional Equipment: Automation

Stanje: zelo dobro (rabljeno), Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 2012, obratovalne ure: 45.208 h, laserske ure: 32.072 h, laserska moč: 3.000 W, najv. debelina pločevine: 20 mm, najv. debelina jeklene pločevine: 20 mm, maks. debelina aluminijaste pločevine: 8 mm, maks. debelina medeninaste pločevine: 6 mm, najv. debelina bakrene pločevine: 6 mm, dolžina mize: 3.000 mm, širina mize: 1.500 mm, potovalna razdalja osi X: 3.000 mm, pomik osi Y: 1.500 mm, pomik po osi Z: 150 mm, hitrost pomika os X: 240 m/min, hitrost podajanja osi Y: 240 m/min, hitrost podajanja os Z: 240 m/min, hitrost pozicioniranja: 240 m/min, natančnost pozicioniranja: 0,02 mm, leto zadnje generalne obnove: 2024, dolžina podajanja os X: 3.000 mm, dolžina pomika po osi Y: 1.500 mm, dolžina podajanja os Z: 115 mm, delovno območje: 3.000 mm, Oprema: dokumentacija / priročnik, hladilna enota, varnostna svetlobna zapora,

Stanje: zelo dobro (rabljeno), Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 2011, laserska moč: 3.000 W, najv. debelina jeklene pločevine: 20 mm, maks. debelina aluminijaste pločevine: 15 mm, maks. debelina medeninaste pločevine: 6 mm, najv. debelina bakrene pločevine: 6 mm, potovalna razdalja osi X: 3.000 mm, pomik osi Y: 1.500 mm, pomik po osi Z: 115 mm, TECHNICAL DETAILS X-axis: 3,000 mm Y-axis: 1,500 mm Z-axis: 115 mm CNC Control: Siemens Sinumerik 840D SL Maximum Load: 900 kg Rapid Traverse (Simultaneous): 265 m/min Laser Laser Source: TruDisk 3001 Sheet Thickness Steel: 20 mm Sheet Thickness Stainless Steel: 15 mm Sheet Thickness Aluminum: 15 mm Sheet Thickness Copper: 6 mm Sheet Thickness Brass: 6 mm Functions: PierceLine, FocusLine, NitroLine, PlasmaLine, ControlLine, FastLine Accuracy Positioning Deviation Pa: 0.05 mm Mean Positioning Deviation Ps: 0.03 mm MACHINE DETAILS Length: 8,300 mm Width: 4,000 mm Height: 2,400 mm Weight: 12,000 kg Power: 6 - 29 kW EQUIPMENT - Torque drive combined with linear direct drives - Enclosed beam guidance via fiber optic cable (LLK) - Machine cooling unit (water-air) - Integrated control cabinets with interior lighting - Automatic pallet changer (longitudinal) - Wide longitudinal conveyor belt - Work area lighting - Positioning laser diode - Spray system - Automatic nozzle cleaning - Universal cutting unit with fully adaptive lens system Godpov A Uzvjfx Ah Djuh - Protective glass against lens contamination - CE marking - Light barriers - Multi-chamber extraction system - Integrated compact dust extraction system - Machine enclosure, certified viewing window, door on right

Stanje: rabljeno, Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 2011, laserska moč: 3.000 W, OPERATING HOURS: NC: 62,904 h Laser On: 40,621 h Year: 2011 3000W STANDARD EQUIPMENT: • Enclosed machine frame with integrated laser unit • Torque drive combined with linear direct drives • Enclosed beam guidance via fiber optic cable (LLK) • Machine cooling unit • Integrated control cabinets with internal lighting • Automatic longitudinal pallet changer • Wide longitudinal conveyor belt • Workspace lighting • Positioning laser diode • Spraying unit • PierceLine • FocusLine • NitroLine • PlasmaLine • Automatic nozzle cleaning TRUMPF Laser: • Solid-state laser TruDisk 3001 with one fiber optic output • Fiber optic cable as per standard layout • Laser cooling unit (water-air) • Excitation via pump diodes with long service life • Laser power control • Laser logbook function Cutting head: • Universal cutting unit with fully adaptive lens system • Single cutting head strategy • Protective glass for lens contamination prevention • ControlLine height control and sheet edge detection Control: • SINUMERIK 840D SL control system • 17" touch color screen • Simple shop floor programming • Advanced shop floor programming • Fast re-production • Integrated technology data • Automatic shutdown • FastLine • FlyLine • Teleservice via internet • Data transfer via USB or RJ-45 network connection Safety: • CE marking • Light barriers • Multi-chamber extraction system • Integrated compact dedusting unit • Machine enclosure, certified viewing panel, right-hand door • Electric rolling roof Guedpfjudy Dyox Ah Deh Extended Equipment: • Viewing panel on left door for enhanced visibility • Storage interface

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2015, Splošni podatki Mere širina: 4.800 mm Mere globina: 8.800 mm Mere višina: 2.400 mm Teža stroja: 12.000 kg Krmilna enota Gujdswzzn Ejpfx Ah Djh Znamka: SIEMENS Model: Sinumerik 840 D Glavni pogon Moč laserja: 5.000 W Tip laserja: TruDisk 5000 fiber Število osi: 3 Pomiki Pomik po osi X: 3.000 mm Pomik po osi Y: 1.500 mm Pomik po osi Z: 115 mm Stroj TRUMPF TruLaser 5030 (L56) fiber 5kW, izdelan leta 2015, je natančen in učinkovit laserski rezalnik. Njegov 3-osni sistem omogoča obdelavo dimenzij do 3.000 x 1.500 x 115 mm. Poganja ga 5.000 W vlakenski laser TruDisk 5000, kar zagotavlja hitrosti rezanja do 265 m/min. Stroj meri 8.800 x 4.800 x 2.400 mm. Upravljanje omogoča Siemens Sinumerik 840 D za visoko natančnost in enostavno uporabo. Za več informacij o stroju nas kontaktirajte. Področja uporabe Rezanje
