Shantui SE215 – Power and Precision for Professional Applications

The Shantui SE215 is a robust 23.8-tonne crawler excavator, developed through close collaboration between Shantui and Komatsu. It combines heavy-duty construction with cutting-edge technology and components from leading manufacturers such as Cummins, Kawasaki, and Nachi.

Technical Highlights

Engine & Drive

• Model: Cummins B6.7, 6-cylinder, water-cooled, turbocharged, common rail

• Output: 129 kW / 2200 rpm

• Emissions Standard: Tier 4 / Euro V

• Displacement: 6.7 litres

Hydraulic System

• Type: Axial piston variable pump (Kawasaki)

• Flow rate: 2 × 250 + 20 l/min

Digging Forces (ISO 6015)

• Bucket: 137–148 kN

• Arm: 99–107 kN

Working Range

• Max. digging depth: 6,510 mm

• Max. reach at ground level: 9,670 mm

• Max. reach: 9,865 mm

• Max. dumping height: 7,170 mm

• Max. digging height: 10,060 mm

• Min. swing radius: 2,970 mm

Bucket

• Type: Trenching bucket

• Capacity: 0.45 – 1.2 m³ (Standard 1.1 m³)

• Width: 1,309 mm

Undercarriage

• Travel motors: Nachi GM41

• Travel speed: 3.3 / 5.3 km/h

• Tractive force: 214 kN

• Gradeability: 35% (70%)

• Track rollers: 2 × 9

• Carrier rollers: 2 × 2

• Track shoes: 2 × 49

Swing Mechanism

• Swing motor: Nachi HM5X130

• Swing speed: 0 – 11 rpm

Capacities

• Fuel tank: 405 litres

• Hydraulic system: 300 litres (Tank: 190 L)

• Cooling system: 33 litres

• Engine oil: 25 litres

Dimensions & Weight

• Operating weight: 23,800 kg

• Ground pressure: 49.3 kPa

• Overall length: 9,630 mm

• Overall width: 2,980 mm

• Overall height: 3,100 mm

• Ground clearance: 470 mm

• Tail swing radius: 2,980 mm

• Track gauge: 2,380 mm

• Track shoe width: 600 mm

⸻

Chedjw Rxg Aepfx Aa Rsc
Benefits for Your Business

• Komatsu DNA through joint venture

• Premium components: Cummins, Kawasaki, Nachi

• Durable, reliable, easy to maintain

• Immediately available from stock at 71735 Eberdingen

• Spare parts & service in Germany

• Optionally available with OilQuick OQ70/55 quick coupler

The Shantui SE215 – Your reliable solution for earthworks, excavation, demolition, and large-scale projects.
