Cilindrični brusilni stroj

SCHAUDT E 450 x 1500

Stanje: rabljeno, Leto izdelave: 1996, središčna višina pri ročični gredi: 1.100 mm, teža obdelovanca (maks.): 80.000 kg, dolžina brušenja: 14.000 mm, premer brusilnega koluta: 915 mm, premer brušenja: 2.000 mm, poteza s peresom: 200 mm, premer tulec: 260 mm, teža obdelovanca med konicami: 80.000.000 g, premer obdelovanca med konicama: 2.000 mm, dolžina obdelovanca med konicami: 14.000 mm, moč: 35 kW (47,59 KM), High-capacity cylindrical grinder with hydrostatic guides POMINI model HD 402/425 – year 1996 – maximum diameter 2000 mm – working length 14000 mm – load capacity between centers 80,000 kg. Possibility of complete retrofit of the electrical unit, manageable upgrades or modifications for application changes. Lsdpfx Adotxlyxekjhd The grinding machine is disconnected and ready for collection.

Stanje: rabljeno, EWAG WS 11 SP je brusilni stroj za orodja, zasnovan za natančnost, visoko točnost in zanesljivost. Delovne zmogljivosti: hod osi X/Y/Z 100 mm, premer brusilnega koluta 75 mm, hitrost vretena obdelovanca 100–1300 obr/min, vertikalna nastavitev brusne glave 100 mm, horizontalno 165°, hitrost brusilnega vretena 2500–7100 obr/min, vpenjanje s kleščami 20 W. Tehnični podatki: priključek 50 Hz 3x380 V, skupna priključna moč 2 kVA, masa stroja cca 400 kg, dimenzije D850׊850×V1580 mm. Oprema: prirobnica za brusilni kolut, odsesavanje prahu, set brusilnih kolutov, svetilka, spiralna brusilna glava W20, pomikalna enota (Z-os) 4 E-M, brusni hod 3 J. Omogoča doseganje strogih toleranc; značilna uporaba v avtomobilski industriji, urarstvu, strojništvu, letalstvu in medicinski tehniki. Lhjdpsxyi I Iofx Adkjd

Leto izdelave: 2012, stanje: dober (rabljeno), Muratec MW120 GT naprodaj Rabljeno, v odličnem stanju. Ogled stroja je možen po dogovoru. Dostava je odgovornost kupca, po potrebi pa lahko pomagamo pri pakiranju in nakladanju. Dobava: EXW Székesfehérvár Lhodoifi D Topfx Adkjd

Stanje: generalkompletno obnovljen (rabljeno), Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 510-1986, CYLINDRICAL GRINDER JOTES SCHAUDT A440X1500 Specifications Max longitudinal travel: 1500 mm Grinding diameter: 298 mm External grinding: Yes Internal grinding: Yes Ljdjw T Ti Djpfx Adkshd Dimensions (L x W x H): 5400 x 2400 x 1600 mm Weight: 4800 kg Operating hours: Power-on hours: Condition: Rebuilt Compliant with local norms: ----- Status: Under power Technical Features - Grinding length [mm]: 1500 - Grinding diameter [mm]: 300 - Manual table feed [mm/turn]: 10 - Table speed range [mm/s]: 0.01 – 5 - Minimum table stroke [mm]: 3 - Wheelhead swivel [˚]: ±90 - Tailstock sleeve taper [Morse no.]: 4 - Grinding wheel dimensions [mm]: 500 x 63 x 203 - Spindle speed [rpm]: 32 – 500 - Main wheel drive motor power [kW]: 5.5 - Workpiece drive motor power [kW]: 0.75 - Hydraulic pump motor power [kW]: 1.5 - Grinding attachment drive motor power [kW]: 0.75 - Overall dimensions [mm]: L=5400 / W=2400 / H=1580 - Machine weight [kg]: 4800

Leto izdelave: 2019, stanje: pripravljen za uporabo (rabljen), A Spinner simultaneous turning center featuring three turrets, complete with extensive accessories, spare parts, and tooling, is available. Travel paths X1/X2/X3: 180mm, Y1/Y2: +/-45mm, Z1/Z3: 704mm, Z2/E2: 620mm/720mm, rapid traverse X/Y/Z: 30m/min, acceleration: 0.5g. Spindle 1: speed: 5000rpm, nose: A6, bore: 65mm, chuck diameter: 210mm, power: 18kW, torque: 115Nm. Spindle 2: speed: 700rpm, nose diameter: 110mm, bore: 42mm, max. chuck diameter: 140mm, max. chuck jaw weight: 1.25kg, power: 16.6kW, torque: 100Nm. Turrets 1/2/3: turret stations: 3x12, speed: 8000rpm, tool holder: BMT 45, power: 4.3kW, torque: 13.6Nm. Machine dimensions X/Y/Z: approx. 2880mm/2130mm/1990mm, weight: approx. 7500kg, operating hours: 27102h, control: Fanuc 31i. Includes Top Automazioni bar feeder, coolant/high-pressure system with 80bar, chip conveyor, fire extinguishing system, a comprehensive tooling package, and additional spare parts. Documentation is available. On-site inspection possible. Ljdpsua E Trefx Adkjhd

Stanje: pripravljen za uporabo (rabljen), potovalna razdalja osi X: 750 mm, pomik osi Y: 750 mm, pomik po osi Z: 725 mm, Oprema: dokumentacija / priročnik, transportni trak za ostružke, 4-axis machining centre, year of manufacture 2016, control: Siemens 840D Solution Line, NC rotary table 360 x 0.001 degrees, double pallet changer, pallet size: 500 x 630 mm, 60-position tool changer, tool holder HSK63, internal coolant supply, gravity belt filter Knoll PF 210/1750, coolant temperature control Hyfra TKR 30, scraper conveyor Knoll 450 K-1, infrared measuring probe Ledpfsrx Sh Aox Adkshd

Stanje: rabljeno, Leto izdelave: 2007, x-pomak 900 mm y-pomak 300 mm z-pomak 1000 mm Upravljanje Siemens 840D Maksimalni prečnik obratka 1600 mm Maksimalni modul 20 mm Lhodewzypuopfx Adkod Prečnik glavnog kružnog oboda 350 mm Težina mašine cca 33.500 kg Potreban prostor cca 10,53 x 6,38 x 4,68 m Tehničke karakteristike: - x-pomak: 900 mm - y-pomak: 300 mm - z-pomak: 1000 mm - Upravljanje: Siemens Sinumerik 840D - Maksimalni prečnik obratka: 1600 mm - Maksimalni modul: 20 mm - Prečnik glavnog kružnog oboda: 350 mm - Prečnik nosača za glodanje: 375 mm - Ukupna priključna snaga: 80 kVa - Težina mašine cca: 33.500 kg - Potreban prostor cca: 10,530 x 6,375 x 4,680 m Brzina posmaka: - X-os: 1 do 3000 mm/min - Y-os: 1 do 3000 mm/min - Z-os: 1 do 4000 mm/min Broj obrtaja vretena u 1/min: - Alat: 26 do 265 - Stol za obradak: 0 do 8 Oprema/pribor: - Motorizovana glava za glodanje M 2 - Nosači za glodanje - Uljni hladnjak - tehnička dokumentacija

Stanje: zelo dobro (rabljeno), dolžina podajanja os X: 450 mm, dolžina pomika po osi Y: 300 mm, dolžina podajanja os Z: 300 mm,

Stanje: novo, POPOLNOMA NOV TRIOSNI OBDELOVALNI CENTER HEIDENHAIN TNC 7 digitalno krovno krmiljenje HEIDENHAIN 16'' TFT zaslon HEIDENHAIN paket (motorji, merilni sistemi in ročno kolo) X-os: 1.430 mm Y-os: 670 mm Z-os: 640 mm Velikost mize: 1.500 x 620 mm Nosilnost mize: 1.200 kg Hitrost vretena: 10.000 min⁻¹ (oljno hlajeno) Sprejem vretena: SK 40-BIG PLUS (BVD 40) Največja moč vretena: 32 kW IKZ – notranji dovod hladilne tekočine – 20 bar Ljdpfohy Atfex Adkehd Hitri pomiki: 30.000 mm/min Pozicijska natančnost: ± 0,005 mm Ponovljivost: ± 0,003 mm Zamenjevalec orodij WZW: 30-kratni (opcijsko do 60) Transporter za ostružke s tečajno verigo Priprava za 4. os (vrtljiva miza) Popolna zaprtje Odgovarjamo le na povpraševanja iz Nemčije.

Stanje: generalkompletno obnovljen (rabljeno), Leto izdelave: 2025, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 1315/451, Completely overhauled: Mechanical, geometry, hydraulic, and electrical components (checked and/or replaced) Grinding Wheelhead Disassembly, cleaning of components, replacement of worn or defective parts, motor overhaul, replacement of bearings, replacement of belts, spindle disassembly, replacement of seals and O-rings, adjustment. New paint. Workhead Disassembly, cleaning of components, replacement of worn or defective parts, motor overhaul, belt replacement. New spindle bearings. New paint. Tailstock Disassembled, inspected and overhauled Hydraulics Disassembly, motor inspection, replacement of hoses, worn or defective parts. Inspection of hydraulic block. X Axis Disassembly, replacement of worn parts such as O-rings, seals, segments, etc., overhaul of hydraulic piston, table grinding. Z Axis Disassembly, table grinding, replacement of worn or defective parts, overhaul of hydraulic piston, new paint. Electrical Cabinet Complete inspection, replacement of various relays. Paintwork Colours: White RAL 9003 and Grey RAL 7011 Geometry as per manufacturer's protocol. Inspection and cleaning of various accessories Origin CH Voltage 380 / 50 / 3 Net weight approx. 2200 kg Customs tariff position 8460.2920 Lsdpfjw U Ry Nsx Adkohd TECHNICAL SPECIFICATIONS Centres distance (nominal) 600 mm Maximum centres distance (with protruding headstock) 750 mm Centres height, standard 125 mm Centres height with interchangeable shoes for headstocks 175 => 250 mm Max. workpiece diameter (125 mm centres height) 250 mm Max. workpiece diameter with interchangeable shoes 350 => 500 mm Table swiveling each direction 10° Max. surface grinding length (max. width = 200 mm) 900 mm Table speed, infinitely variable hydraulically 0 - 6 m/min approx. Table reversal dwell time 0-5 s External grinding wheel, diameter – width – bore 400 x 50 x 127 mm Surface grinding wheel 250 x 13 x 76 mm Grinding wheel spindle speed 1500/1700/2200/3600 rpm Wheelhead swiveling 270° With indexing every 90° Vertical movement of wheelhead, centre height 125-350 mm Transversal travel of wheelhead 285 mm Hydraulic rapid feed and return stroke 40 mm Incremental feed of wheel by table reversal 0.001 - 0.03 mm/dia Continuous infeed for plunge grinding 0 - 0.9 mm/dia Micrometric infeed stop, per division 0.001 mm/dia Workhead swiveling 360° Workhead spindle speed, infinitely variable (normal/special), rpm 20-400/10-400 Internal taper of workhead/tailstock 5/3 Morse Wheelhead motor, approx. 4 HP All technical data are given without guarantee and subject to errors or omissions.
