Vrtljiva miza Varilna miza Vrtljiva nagibna miza

Heinrichsglück DKH500-P600

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2003, x-gib: 850 mm y-gib: 700 mm z-gib: 500 mm Nadzorni sistem Heidenhain iTNC 530 Nosilec orodja HSK 63 Delovna napetost 400 V Nadzorna napetost 24 V Masa stroja približno 10,5 t - Trenutno stanje C 40 U: o Vertikalna os BAZ o Štiri osi o Gibi osi X 850 mm, Y 700 mm, Z 500 mm Bsdpfx Aoz Ebrasiqedh o Velikost mize X 1070 mm, Y 700 mm o Revija za orodja, karusel, 40 mest o Največja dolžina orodja v reviji 300 mm o Vreteno HSK63, 10.000 vrt/min, 25 kW, 159 Nm o Sistem za hlajenje AK, IKZ 40 bar, 1.000 litrov prostornine, jekleni filter o Zračni curk IK & AK o Sistem MMS MHT o Transportni sistem za kovinske opilke o Polikarbonatna plošča brez Rotoclear o Nadzor stroja Heidenhain iTNC 530 o Sistem za sesanje emulzijske megice (priprava) o Dimenzije stroja s sistemom za hlajenje: 3930 mm x 4400 mm x 3040 mm o Laserski merilni sistem za orodja, vključno z nadzorom poškodb o 3D-merilna sonda o Delovni čas vretena: 14.578 ur o Delovni čas stroja: 47.069 ur

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2015, Max. premer obdelovanca: 400 mm Max. dolžina obdelovanca: 300 mm Max. premer vpenjalne glave: 500 mm Obodni premer: 520 mm Pomik osi X: 1.110 mm Pomik osi Z: 595 mm Glavno vreteno: moč (pri 40 / 100 % ED): 47/34 kW Glavno vreteno: navor (pri 40 / 100 % ED): 600 Nm Glavno vreteno: največje število vrt./min: 2.850 Krmilje: Fanuc 31i Brez Y osi Bdedsxy Ac Sopfx Aiqoh

Stanje: rabljeno, TECHNICAL DATA - Number of axes: 10 - Number of spindles: 2 MAIN SPINDLE - Spindle drive power: 24 kW - Spindle speed: 5,000 rpm - Max. bar diameter: 65 mm - Minimum C-axis resolution: 0.001° COUNTER SPINDLE - Spindle drive power: 24 kW - Spindle speed: 5,000 rpm - Max. bar diameter: 65 mm - Minimum C-axis resolution: 0.001° - Travel: 390 / 600 mm TURNING-MILLING SPINDLE - X-axis travel: 350 mm - Y-axis travel: ±80 mm - B-axis stroke: 270° - Minimum B-axis resolution: 0.001° - Tool type: HSK-T40 - Spindle speed: 18,000 rpm - Spindle drive power: 11 kW - Fixed tools on electrospindle for milling: 6 x VDI25 LOWER TURNING AND MILLING SPINDLE - Y-axis travel: ±80 mm - B-axis stroke: 270° - Minimum B-axis resolution: 0.001° - Tool type: HSK-T40 Bdsdpfxsv Ig Avs Aiqsh - Spindle speed: 18,000 rpm - Spindle drive power: 11 kW - Fixed tools on electrospindle for milling: 6 x VDI25 TOOL CHANGER - Tool changer type: Bar loader - Number of tools in magazine: 80 - Tool change time: 4.5 s ELECTRICAL SUPPLY - Supply voltage: 400 V - Total power: 68 kW WEIGHT AND DIMENSIONS - Machine height: 2,500 mm - Machine weight: 11,000 kg MACHINE HOURS - Spindle hours: 19,781 h - Turning-milling spindle hours: 9,713 h ACCESSORIES - Control: Siemens Sinumerik 840D SL - Coolant tank * with high-pressure pump * with paper filter * internal coolant supply (ICS) - Chip conveyor - Spindle cooling - Parts removal

Stanje: zelo dobro (rabljeno), Leto izdelave: 2012, Funkcionalnost: popolnoma funkcionalen, 12 mesecev garancije, demonstracijski model, zelo dobro stanje, samo približno 250 delovnih ur, takoj na voljo. - v skladu s standardom DIN EN 1539 za materiale, ki vsebujejo topila - maksimalna temperatura: 300 °C - notranji prostor pečice: 750 x 750 x 750 mm (Š x G x V) - zunanje mere: 1510 x 1150 x 2200 mm (Š x G x V) - regulator temperature JUMO dTRON 04 - dovoljena količina topila: maks. 19,30 g - grelna moč: maks. 21,78 kW - priključna moč: 22,5 kVA - nazivni tok: 32,6 A - priključitev: 400 V 3L/PE 50 Hz - kabel s 63A vtičem, možna tudi fiksna priključitev, v tem primeru je potrebna varovalka 35 ali 50 A - vključno z 1 rešetkastim dnom - teža: 550 kg - dokumentacija, izjava o skladnosti CE Ogled v našem skladišču po predhodnem dogovoru. Bedpfx Aisiq Uv Neqedh Peč, peči, industrijska peč, peč s kroženjem zraka, komorna peč, žarilna peč, toplotna peč, sušilna peč, temperaturna peč, sušilnica za lak, peč za topila

Stanje: novo, Saw blade diameter: 370 mm Cutting capacity at 90 degrees (round): 120 mm Cutting capacity at 90 degrees (square): 100 mm Cutting capacity at 90 degrees (rectangular): 180x100 mm Working height: 925 mm Saw blade speeds: 15 - 70 rpm Total power requirement: 1.8/2.2 kW Machine weight: approx. 0.71 t Bedpfod Iin Hjx Aiqodh Space requirement: approx. 1.9 x 1.45 x 2.1 m SPECIAL OFFER PRICE!!! High-Performance Vertical Circular Saw, Hydropneumatic Fully Automatic (20192) · Mitre cutting left 60° / right 45° · Hydro-pneumatic control of the saw unit · Electro-pneumatic automatic material feed unit · Smooth-running, high-performance worm drive with large gear ratio, integrated into a robust cast housing for optimal cutting results · Vise with double clamping arm for low-burr cuts, additionally with quick lateral positioning for mitre adjustment · Precision prismatic guide for the gearbox head, laterally adjustable · Particularly stable base frame with integrated automatic coolant system · Large chip drawer · Chip removal brush in the saw blade guard MPS control system: · Storage of cut start/end positions · Display of current consumption, piece count, cutting time... · Adjustable water cooling · Cutting pressure regulator IMPORTANT: Price does NOT include saw blade! (Saw blade price €204)

Stanje: zelo dobro (rabljeno), Leto izdelave: 1999, Upravljalni sistem Heidenhain TNC 426 Gibljive poti X/Y/Z: 1250 x 880 x 800 mm Število vrtljajev: 8.000 min-1 Revija za orodja za 60 orodij, vpenjalni sistem SK 50 Univerzalna glava za rezkanje +0° / -90° NC vrtljiva miza 1250 x 1000 mm Bjdpfjzqv A Tox Aiqjdh Odstranjevalec žagovine Merilna sonda

Stanje: dober (rabljeno), Leto izdelave: 2000, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 018.0179.90.035, (Please state your offer price) Sales only within Europe, including Turkey Price without packaging; Delivery condition: FCA (machine location) ===== For technical specifications, please refer to the attached handout. All warranties are excluded. Bdodpeyh R Uwofx Aiqoh We assume no liability for the accuracy of technical data and year of manufacture, for the completeness of accessories and tooling, or for compliance with all safety and environmental protection requirements stipulated in accident prevention regulations. No sales to private individuals.

Stanje: novo, Table length 3000 mm Table width 1500 mm Table height 200 mm Weight 1500 kg Manufacturer: GERD WOLFF Technical Details: • Length: 3000 mm • Width: 1500 mm • Height: 200 mm • Weight: 1500 kg • Hole diameter: 28 mm • Hole spacing: 100 mm • Plate thickness: 25 mm Advantages and Features • 3-day gas nitriding process • Enhanced corrosion resistance • Anti-adhesion protection against welding spatter • Maximum load capacity • Increased fatigue strength • Enhanced vibration resistance • Fine scale markings • Reinforced with weld seams and ribs on the underside • Optimal working height of 820-865 mm • 8x height-adjustable support legs • Compatible accessory set available (optional) Our welding tables are manufactured from HT 300 cast quality and are nitrided as a single piece after machining. Furthermore, all tables feature precise fine graduation, engraved using laser technology. To ensure excellent stability, our welding tables are reinforced with welded seams and ribs on the underside (see images). Additionally, they undergo a 3-day gas nitriding process that notably increases corrosion resistance as well as fatigue and vibration strength. All our tables come with adjustable legs. The minimum adjustment range is 620 mm, and the maximum is 665 mm. This allows for a variable working height from 820 to 865 mm. Other available dimensions: • 1000 x 1000 x 200 • 2000 x 1000 x 200 • 1200 x 1200 x 200 • 1500 x 1000 x 200 • 1500 x 1500 x 200 • 1500 x 2000 x 200 • 2000 x 3000 x 200 • 3000 x 1500 x 200 • 3000 x 2000 x 200 Bdedpfxjymf Rtj Aiqjh • 4000 x 2000 x 200 Images do not correspond to the original size and are for illustration purposes only. Our welding tables are manufactured for our distribution brand "GERD WOLFF Maschinenfabrik" by a renowned manufacturer. 3D Welding Table – 3D Clamping Fixtures – 3D Precision Welding Table

Stanje: dober (rabljeno), Leto izdelave: 2016, Funkcionalnost: popolnoma funkcionalen, Trenutno se izvaja obnova stroja v vrednosti 90.000 €, Maho DMF 260 -7 / obdelovalni center s 5 osemi, Letnik izdelave 2016, Nadzorni sistem Heidenhain ITNC 530, Hod osi X/Y/Z 2600/700/700 mm, Stacionarna miza z integrirano NC rotacijsko mizo, Os B v glavi za rezanje, brezstopenjska, Hitrost vretena do 14.000 vrt/min, Vpenjalna glava HSK A63, Količina hlajevalne tekočine 60-kratna, IKZ 40 bar, Filtrirni sistem s papirnatimi trakovi, 3D merilna sonda Heidenhain TS 649, Bodpozxfz Ijfx Aiqjdh 3D sistem za hitro nastavitev, Nadzorni sistem za zaščito stroja, Električno ročno kolo, 3D podatkovni model.

Stanje: novo, Table length: 2400 mm Table width: 1200 mm Table height: 200 mm Material thickness: 25 mm Weight: 920 kg Manufacturer: GERD WOLFF Technical details: • Length: 2400 mm • Width: 1200 mm • Height: 200 mm • Weight: 920 kg • Bore diameter: 28 mm • Bore spacing: 100 mm • Plate thickness: 25 mm Advantages and Features • 3-day gas nitriding process • Improved corrosion resistance • Anti-adhesion protection against weld spatter • Maximum load capacity • Enhanced fatigue strength • Increased vibration resistance • Fine laser-engraved scale • Reinforcement by weld seams and ribs on the underside • Optimum working height of 820–865 mm • 6 height-adjustable support legs • Matching accessory set available (optional) Our welding tables are manufactured using HT 300 cast quality and are nitrided as a single unit after mechanical machining. In addition, they feature a precise fine scale engraved using laser technology. To ensure adequate stability, our welding tables are reinforced with weld seams and ribs on the underside (see images). Furthermore, they undergo a 3-day gas nitriding process, which increases the tables’ corrosion resistance as well as their durability and vibration fatigue strength. All our tables are equipped with adjustable legs. The minimum adjustment range is 620 mm; the maximum is 665 mm. This allows for a variable working height from 820 to 865 mm. Other available dimensions: • 1000 x 1000 x 200 • 2000 x 1000 x 200 • 1200 x 1200 x 200 • 1500 x 1000 x 200 Bodpfx Ajynbmmoiqjdh • 1500 x 1500 x 200 • 1500 x 2000 x 200 • 2000 x 3000 x 200 • 3000 x 1500 x 200 • 3000 x 2000 x 200 • 4000 x 2000 x 200 The illustrations do not depict the original size and are for reference only. Our welding tables are manufactured by a renowned producer for our distribution brand "GERD WOLLF Maschinenfabrik." 3D welding table – 3D clamping systems – 3D precision welding table
