E-CG-Upravljanje

Engel

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2004, obratovalne ure: 70.029 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 51561, vpenjalna sila: 2.300 kN, premer vijaka: 135 mm, tlak vbrizgavanja: 1.600 letvica, odmični hod: 3.800 mm, višina orodja: 1.890 mm, TEHNIČNI PODATKI Zapiralna sila: 2.300 kN Velikost plošč (V x Š): 2.900 x 2.500 mm Razdalja med stebri (V x Š): 2.000 x 1.600 mm Minimalna/maksimalna višina orodja: 700 mm / 1.890 mm Maksimalni hod odpiranja: 3.800 mm Hsdoy T Hx Hepfx Apbon Vbrizgalna enota Premer polža: 135 mm Volumen vbrizga: 8.870 cm³ Teža vbrizga (PS): 8.071 g Vbrizgalni tlak: 1.600 bar PODATKI O STROJU Neto teža (s krmilno omaro): 113 t + 18 t Obratovalne ure: 70.029 h

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2011, obratovalne ure: 61.666 h, Funkcionalnost: popolnoma funkcionalen, vpenjalna sila: 6.500 kN, premer vijaka: 90 mm, premer stebra: 175 mm, injekcijska masa: 2.520 g, odmični hod: 1.400 mm, The machine is in excellent condition, all hydraulic hoses were replaced in Q4 2024! TECHNICAL DETAILS Hedpfx Apjy T Hfyobsn Clamping force: 6,500 kN Tie bar spacing (H x V): 1,100 x 960 mm Platen size (H x V): 1,510 x 1,440 mm Mold height (min./max.): 650 / 1,150 mm Opening stroke: 1,400 mm Max. distance between platens: 2,050 mm Max. mold weight: 11,000 kg Ejector force: 95 kN Ejector stroke: 250 mm Tie bar diameter: 175 mm Injection unit (Unit 5550) Screw diameter: 90 mm Max. shot volume: 2,740 cm³ Max. shot weight (PS): 2,520 g Injection pressure (max./boost): 2,180 bar Injection pressure (standard): 1,910 bar Screw L/D ratio: 20 Screw stroke: 430 mm Max. screw speed: 148 rpm Plasticizing rate: 77 g/s Nozzle contact force: 150 kN MACHINE DETAILS Control: CC200 Drive and supply Installed drive power: 90 kW Heater power: 56 kW Number of heating zones: 6 Hydraulic tank capacity: 1,000 l Installed drive power: 90 kW Operating hours: 61,606 h EQUIPMENT Robot: Viper 40 Core pulls: 6 hydraulic circuits on the moving platen 2 hydraulic circuits on the fixed platen Cascade valves: 4 units (mounted on the fixed platen)

Stanje: rabljeno, Leto izdelave: 2005, Technical details: Screw diameter: 70 mm Shot weight in polystyrene: 687 g/PS Clamping force: 3,000 kN Hsdpfx Aswftr Depbjn Approx. machine weight: 19.4 t From series production Preheating unit and air soaking unit are not included in the package!

Stanje: zelo dobro (rabljeno), Leto izdelave: 2018, Vpenjalna sila: 1700 t Hjdpfjzatkhox Apben Premer vijaka: 105 mm Razdalja med opornimi stebri spredaj (V): 1415 mm Razdalja med opornimi stebri zadaj (H): 1850 mm Volumen izstrelka: 4070 cm³ Tip: večkomponentni Pogon: hidravlični

Stanje: zelo dobro (rabljeno), Leto izdelave: 2019, Vpenjalna sila: 650 t Hodpfxozaqygo Apben Premer vijaka: 60 mm Razdalja med podpornimi drogovi (vertikalno): 960 mm Razdalja med podpornimi palicami (horizontalno): 1100 mm Prostornina brizganja: 890 cm³ Tip: Horizontalen Pogon: Hidravličen

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2024, vpenjalna sila: 2.700 kN, Engel DUO 36060/2700 TECH (2024) Hjdpfx Apey U Hu Robon

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2024, vpenjalna sila: 24.000 kN, ENGEL DUO 23060/2400 TECH Manufacturer: ENGEL CLAMPING UNIT Clamping force: 24,000 kN (2,400 t) Opening stroke: 3,200 mm Max. mold mounting height: 4,000 mm Min. mold height: 800 mm Max. mold height: 2,000 mm Tie bar spacing (H × V): 2,020 × 1,620 mm Platen dimensions (H × V): 2,700 × 2,430 mm Opening force: 614 kN Opening force with pressure plate: 1,600 kN Dry cycle time (Euromap 6): 5.4 s INJECTION UNIT Screw diameter: 150 mm L/D ratio: 25:1 Screw stroke: 680 mm Shot volume: 12,020 cm³ Theoretical shot weight (PS): approx. 10.9 kg Injection rate: 2,121 cm³/s Injection pressure (regenerative): 1,601 bar Max. injection pressure: 1,900 bar Screw speed: 90 rpm Max. screw speed: 115 rpm Screw torque: 18,600 Nm Reduced torque at max. speed: 14,550 Nm Plasticizing capacity (3-zone screw): 235 g/s Plasticizing capacity (barrier screw): 322 g/s NOZZLE Nozzle travel: 1,100 mm Nozzle contact force: 210 kN EJECTOR Ejector stroke: 400 mm Ejector force forward: 420 kN Ejector force retraction: 420 kN HEATING SYSTEM Heater zones incl. nozzle: 10 Installed heating capacity: 97.4 kW DRIVE Installed motor power: 265 kW Hydraulic oil tank capacity: 1,600 l COOLING REQUIREMENT Cooling capacity: 45.2 kW Water consumption (32°C inlet): 6.6 m³/h Cores: 3+3 Hjdey U Hphepfx Apben Heater zones: 160 Cascade controllers: 56

Stanje: nepreverjeno (rabljeno), Leto izdelave: 2010, številka stroja/vozila: 61015538, This Engel injection molding machine, model victory 1050/220 tech, year of manufacture presumably 2010, is being auctioned as part of our online auction "Site Closure Wirthwein Friedberg GmbH & Co. KG – Machinery, Tools, Workshop Equipment & much more." Included in the lot are an MB Conveyors conveyor belt (year 2012) and a motan mixing unit (year 2024). You can find this and many other items from the fields of injection molding technology, production and workshop equipment, temperature control devices, lifting technology, EDM machines, measuring equipment, and transport & social room furnishings on our RESTLOS auction platform! Engel Injection Molding Machine Nameplate data: Manufacturer: Engel Serial No.: 177100 Year of manufacture: 2010 (partially obscured, assumed) Model: victory 1050/220 tech Weight: 12,200 kg motan Mixing Unit Nameplate data: Hedjy Uzdaspfx Apben Manufacturer: motan holding Designation: Mixing Unit Model: Mixing module - 2l - MB Rated voltage (UN): 24 V DC Control voltage (Us): 24 V DC Current (IL): 2.7 A Max. load (mmax): 8 kg Year of manufacture: 2024 Serial number (SN): 677A01A24 14293 RA: BM02A CE marking: present UKCA marking: present MB Conveyors Conveyor Belt Nameplate data: Manufacturer: MB Conveyors Model: N-CPR LOW-COST Year of manufacture: 2012 Matriculation no.: B20032 Voltage: 400 V CE marking: present Scope of delivery as shown. No additional items shown in the photos are included. Functionality untested.

Stanje: dober (rabljeno), Leto izdelave: 2007, Zapiralna sila: 1000 t Premer vijaka: 105 mm Razdalja med stebri V: 1150 mm Razdalja med stebri H: 1400 mm Prostornina brizga: 4160 cm3 Tip: Horizontalni Pogon: Hidravlični Hjdpfxoy Ukfmo Apbsn

Stanje: dober (rabljeno), Leto izdelave: 2016, Ref. No.: 18657 Manufacturer: ENGEL Model: e-victory 440/160 CC300 ecodrive Year of manufacture: 2016 Clamping unit Clamping force: 160 tons Opening stroke: 900 mm Minimum mould height: 300 mm Maximum mould height: 600 mm Plate dimensions (W x H): 750 x 750 mm Injection unit Screw diameter: 35 mm Injection volume: 168 cm³ Shot weight (PS): 151 g Injection pressure: 2400 bar Dimensions and weights Dimensions LxWxH: 5.7 x 1.8 x 2.2 m Machine weight: 10,200 kg Additional information: Tie-barless design + electric injection unit = maximum flexibility and precision ENGEL e-victory 440/160: This is a hybrid machine (servo-hydraulic + electric) Mode of operation Electric component: * Injection unit (screw movement) * Ensures very high precision and process stability ✔ Hydraulic component: * Clamping unit (mould closing) * Maintains pressure in an energy-efficient manner without additional energy consumption This system combines: * The precision of an electric machine * With the power and efficiency of a hydraulic unit This is a modern servo-hydraulic injection moulding machine from the proven ENGEL e-victory series. This line is known for its energy-efficient drive technology, high precision, and space-saving tie-barless design. The machine offers a clamping force of 160 tons and is ideal for technical plastic parts as well as demanding applications in automotive, medical technology, and industrial sectors. Key features: * Tie-barless design for maximum mould flexibility * Servo-hydraulic drive for high energy efficiency * Precise and stable process management * Compact design with large mounting area * Modern ENGEL control system Hsdpfx Asy Ipgpepbon The machine was manufactured in 2016 and is in excellent visual and technical condition, as shown in the photos. Its tie-barless construction provides clear advantages for large or complex moulds and enables very flexible production.
