Obdelovalni center

Akira Seiki Dugard 1350 XP

Stanje: rabljeno, Leto izdelave: 2007, Swing diameter 300 mm Turning length 600 mm Control FANUC, 18i-TB Swing diameter over cross slide 230 mm Travel X1 165 mm Travel Z1 700 mm Travel X2 190 mm Travel Z2 720 mm Travel Y +/- 50 mm Main spindle bore 76 mm Main spindle speed 5,000 rpm Main spindle motor 22 kW Spindle torque 208 Nm Counter spindle bore 76 mm Counter spindle speed 5,000 rpm Counter spindle motor 22 kW Spindle torque 208 Nm Tool turret 2 x 12 stations Number of live tool stations 2 x 12 Live tooling speed 5,000 rpm Torque 47 Nm Tool drive power 5.5 kW C-axis resolution 0.001° Rapid traverse X + Z axes 20 / 40 m/min Rapid traverse Y axis 7.5 m/min Rsdjxn Amtjpfx Abhjn Total connected load 68.4 kVA Machine weight approx. 7.8 t Accessories: Collet chuck on main spindle, hydraulic 3-jaw chuck KITAGAWA BB208, 210 mm diameter, on counter spindle, various tool holders for turret, short bar loader by HYDRAFEED, model MULTIFEED MX-1B for bar diameter 3 - 80 mm and bar lengths up to 1650 mm; chip conveyor, coolant system with band filter unit

Stanje: dober (rabljeno), Leto izdelave: 2002, Control system HEIDENHAIN TNC 430 Spindle speed 20 - 9,000 rpm Travels X = 500, Y = 400, Z = 400 mm Tool holder SK 40 Rsdjwglfxspfx Abhen Tool changer with 16 stations Rotary table with B and C axis Clamping area Ø 700 x 500 mm Max. table load 200 kg Infrared probe for workpiece measurement

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2023, DMG CMX 50 Krmilnik: Siemens 840D sl Pomik X: 500 mm Pomik Y: 450 mm Pomik Z: 400 mm Leto izdelave: 2023 Rsdpfex Sqyfox Abhsn Teža: 4700 kg

Stanje: dober (rabljeno), Leto izdelave: 2019, CNC stružno-rezkalni center Tip stroja: Spinner TC 800 - 85 MCY Krmiljenje: Siemens 840 D Shopturn Leto izdelave: 2019 Na voljo od: takoj TEHNIČNI PODATKI: Maks. dolžina struženja: 900 mm Premer struženja: 500 mm Območje vrtenja: 2.600 - 4.000 1/min C-os Prehod palice: 85 mm Konjiček Pomiki: X-os: 360 mm Y-os: -55 / +65 +/- mm Z-os: 900 mm Število revolverjev: 1 Mesta za orodje: 12 Rsdpfx Abexdc Sushsn Pogonska orodja: 12 Vpenjalo orodij: BMT 65 Oprema: Transporter ostružkov Elektronski ročni kolešček

Stanje: dober (rabljeno), Funkcionalnost: popolnoma funkcionalen, Leto izdelave: 1991, najv. debelina jeklene pločevine: 16 mm, dolžina rezanja (maks.): 6.000 mm, HIDRAVLIČNE ŠKARJE LVD MVSB 62/16 Serijska številka: 18478 Leto izdelave: 06/1991 TEHNIČNE SPECIFIKACIJE Maks. debelina pločevine St45: 16 mm Dolžina reza: 6200 mm Razdalja med stebri: 6400 mm Izmaknjenost (grlo): 60 mm Območje zadnjega odmika: 1000 mm Min. kot rezanja: 0,5 ° Maks. kot rezanja: 2,5 ° Min. število rezov/min.: 6 Maks. število rezov/min.: 25 Min. zračnost nožev: 0,05 mm Maks. zračnost nožev: 1,6 mm Moč motorja: 30 kW Približna masa: 35.000 kg Dimenzije (DxŠxV): 7100 x 2400 x 3000 mm Rsdpfoumhm Aex Abhon Priložena oprema: - ELGO P85 “GO-TO” krmilnik za zadnji odmik - Električna nastavitev zadnjega odmika do 1000 mm - 1x čelna podpora 2 m, ena s 90° kotno roko, čelna podpora L2000 mm - Nožno stikalo - Kroglični ležaji na mizi - Nastavljiv zadnji odmik z ročno hidravlično črpalko

Stanje: zelo dobro (rabljeno), stružna dolžina: 5.500 mm, Manufacturer: WEIPERT Model: W1400 Control system: R&D MTC3 Turning length: 5,500 mm Swing over bed Ø: 1,400 mm Swing over cross slide: 960 mm Length: 9,000 mm Rjdpewzhzlsfx Abhon Width: 2,900 mm Height: 2,900 mm Weight: 32,000 kg

Stanje: zelo dobro (rabljeno), Leto izdelave: 2006, Control system: ELB PLC Grinding area: Length X 1000 mm Width Z 750 mm Height Y 400 mm Magnetic chuck 1000 x 700 mm Rsdpevwl Ipefx Abhjn Table load capacity (without magnetic plate): 1100 kg Longitudinal axis X: Table speed 2–26 m/min Maximum longitudinal stroke 1100 mm Vertical axis Y: Vertical stroke 400 mm Maximum feed speed 1200 mm/min Minimum vertical infeed 0.001 mm Cross axis Z: Maximum cross stroke 620 mm Maximum feed speed 2000 mm/min Minimum cross infeed 0.001 mm Grinding spindle: Taper 75 mm Drive 22 kW Speed range 1450 rpm Grinding wheel dimensions: 450 x 150 x 203.2 mm Machine footprint (without control panel) LxWxH: 3550 x 2750 x 3230 mm Total machine weight: 7300 kg

Leto izdelave: 1971, Stanje: dober (rabljeno), Decoiler – expanding mandrel decoiler with coil lifting table Strip width: 1,200 mm Strip thickness: 0.3 – 5 mm Rodpfx Abed Ha E Sohon Coil weight: 10 t Mandrel Ø: 508 mm

Leto izdelave: 1976, Stanje: dober (rabljeno), Bandwidth: 300 - 1,350 mm Strip thickness: 0.35 - 3 mm Coil weight: 12.5 t Rsdpfx Aebh Ubwebhen Mandrel Ø: 508 mm

Stanje: rabljeno, Leto izdelave: 2007, Turning diameter: 300 mm Swing diameter over bed: 430 mm Rjdpjwx R Rksfx Abhon Swing diameter over carriage: 300 mm Control: SIEMENS, SINUMERIK 840 D Travel - X: 160 mm Travel - Z: 510 mm Max. part length: 480 mm Main spindle bore: 53 mm Main spindle speed: 0 - 7000 rpm Spindle nose: DIN 55026 A2-5 Spindle torque: 100 Nm Main spindle motor: 15 kW Sub-spindle bore: 53 mm Sub-spindle speed: 0 - 7000 rpm Spindle nose: DIN 55026 A2-5 Spindle torque: 100 Nm Sub-spindle motor: 15 kW C-axis resolution: 0.001° C-axis rapid traverse: 1000 rpm Tool turret: 1 x 12 stations Number of driven tool stations: 1 x 12 Tool holder: cylindrical shank (DIN 69880) VDI 25 Driven tool speed: 0 - 8000 rpm Torque: 16 Nm Power: 4 kW Feed force X/Z axis: 4000 / 6000 N Rapid traverse X-axis: 24 m/min Rapid traverse Z-axis: 30 m/min Total power requirement: 38 kVA Machine weight: approx. 4 t Machine dimensions (L x W x H): 2.65 x 1.84 x 2.32 m Accessories: collet chuck 173 E on main spindle, collet chuck 163 E on sub-spindle, bar feeder manufacturer FMB, type turbo 3-36/3200 A, year 2018 for bar diameters up to 36 mm and bar lengths up to 3200 mm; various tool holders for turret (no driven holders), coolant system
