Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 1991, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 9101291, potovalna razdalja osi X: 2.500 mm, pomik osi Y: 940 mm, pomik po osi Z: 1.000 mm, največja hitrost vretena: 2.100 obr/min, dolžina mize: 2.600 mm, TEHNIČNI PODATKI Gedpfx Asxdaiqeh Djkc Pomiki X-os: 2.500 mm Y-os: 940 mm Z-os: 1.000 mm Hitrost vretena: 2.100 vrt/min Dolžina mize: 2.600 mm PODROBNOSTI O STROJU Krmiljenje: Heidenhain 355 Teža: 10.000 kg OPREMA Glava za rezkanje SK50

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2006, obratovalne ure: 3.010 h, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 1.000 mm, pomik osi Y: 530 mm, pomik po osi Z: 510 mm, največja hitrost vretena: 10.000 obr/min, proizvajalec krmilnikov: Fanuc, TEHNIČNE PODROBNOSTI Pomik X: 1.000 mm Pomik Y: 530 mm Pomik Z: 510 mm Število osi: 3 Maks. število vrtljajev vretena: 10.000 min⁻¹ Velikost mize – dolžina: 1.200 mm Velikost mize – širina: 510 mm PODROBNOSTI STROJA Tip krmiljenja: Fanuc Mere in teža Mere (D x Š x V): 2.850 x 2.150 x 2.300 mm Lastna masa: 6.000 kg Transportni paketi: 3 Gsdpfx Asxcn N Ajh Dskc Moč motorja: 11,0 kW Delovne ure: 3.010 h OPREMA Dokumentacija CE oznaka

Stanje: dober (rabljeno), Leto izdelave: 2014, obratovalne ure: 921 h, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 1.600 mm, pomik osi Y: 700 mm, pomik po osi Z: 640 mm, hitrost pomika os X: 12 m/min, hitrost podajanja osi Y: 12 m/min, hitrost podajanja os Z: 12 m/min, skupna masa: 9.800 kg, največja hitrost vretena: 6.000 obr/min, Oprema: transportni trak za ostružke, Hardinge GX-1600 (Leto 2014) Krmilni sistem: FANUC Oi-MD Vključen transporter Kapaciteta orodjarskega magazina: 30 orodij Pomik X-osi: 1.600 mm Pomik Y-osi: 700 mm Pomik Z-osi: 640 mm Dimenzije mize: 700 mm x 1.700 mm Največja nosilnost mize: 1.500 kg Hitrost vretena: 6.000 vrt/min Vretenasti konus: CAT 50 Moč motorja vretena: 18,6 kW (25 KM) Podajalne hitrosti (vse osi): 2,54 – 12.000 mm/min Hitri pomik: 29.159 mm/min Razdalja med delovno mizo in čelom vretena: – Maksimalno: 790 mm Gksdpfow Hzu Njx Ah Dec – Minimalno: 155 mm Dimenzije stroja (D x Š x V): 3.900 mm x 2.723 mm x 2.878 mm Teža stroja: pribl. 9.800 kg

Stanje: rabljeno, Leto izdelave: 1996, potovalna razdalja osi X: 2.500 mm, pomik osi Y: 1.000 mm, pomik po osi Z: 1.000 mm, največja hitrost vrtenja: 3.000 obr/min, vrtljajska hitrost (min.): 50 obr/min, X AXIS TRAVEL: 2500 MM Y AXIS TRAVEL: 1000 MM Z AXIS TRAVEL: 1000 MM FIXED TABLE: 1600 X 800 MM – MAX LOAD 5000 KG ROTARY TABLE: 750 X 750 MM – MAX LOAD 5000 KG RAPID TRAVERSE X/Y/Z: 10,000 MM/MIN SPINDLE TAPER: ISO 50 SPINDLE SPEED: 50 – 3000 RPM Gedjwz H Hmepfx Ah Dokc NUMBER OF SPEED RANGES: 2 CNC CONTROL: HEIDENHAIN TNC 407 AUTOMATIC UNIVERSAL HEAD (HORIZONTAL – VERTICAL) AUTOMATIC TOOL CHANGER

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2007, potovalna razdalja osi X: 3.000 mm, pomik osi Y: 900 mm, pomik po osi Z: 900 mm, FIXED BED MILLING MACHINE LAGUN TECHNICAL SPECIFICATIONS Brand: Lagun Model: GBM 31 Table size: 3100 x 900 mm CNC: Heidenhain iTNC 530 X-axis travel: 3000 mm Y-axis travel: 900 mm Z-axis travel: 900 mm Table load capacity: 6000 kg Spindle speed: 3000 rpm Gsdowyv Nuopfx Ah Dekc Feed rate: 20000 mm/min Tool magazine capacity: 24 tools Main motor power: 22/27 kW Automatic indexing head: 2.5 x 2.5º The machine is not equipped with through-spindle coolant. PRICE AND FURTHER INFORMATION ON REQUEST (CNC, SIEMENS, HAAS, LAGUN, FAGOR, CINCINNATI, HEIDENHAIN, MACHINING, PINACHO, MORI SEIKI, MILLING MACHINE, LATHE, GRINDER, BORING MACHINE, PRESS, LASER, SHEAR, PRESS BRAKE)

Stanje: pripravljen za uporabo (rabljen), 1 used CNC bed milling machine with Heidenhain control system. Additionally equipped with a rotary table. Gkjdpewxxzqsfx Ah Djc Further technical specifications will be added.

Stanje: rabljeno, Leto izdelave: 1993,

Stanje: novo, The VECTOR 1400 M Si is an outstanding vertical machining center in the C-frame CNC machine category, specifically designed for the machining of large and heavy workpieces. Its robust machine base, crafted from high-quality Meehanite cast iron, ensures consistently high precision even in multi-shift production, thanks to its low center of gravity and premium components. The comprehensive equipment includes a 24-position tool changer with double-arm gripper and a 30-bar through-spindle coolant system, providing optimal cutting quality and fast setup times. Stability is further enhanced by large guideway spacings and fully enclosed roller linear guides. Optional automation solutions are available to further increase your productivity. Knuth additionally offers a two-year warranty on this high-performance machining center. Take advantage now and order your VECTOR 1400 M Si – for a tailored solution in the category of vertical machining centers! Gkjdpfx Aoww T Trsh Djc

Stanje: Okvarjen nosilec rezervnih delov (rabljen), Leto izdelave: 1996, Funkcionalnost: omejena funkcionalnost, številka stroja/vozila: 025, potovalna razdalja osi X: 1.500 mm, pomik osi Y: 800 mm, pomik po osi Z: 600 mm, Auerbach FBE 1500 Milling Machine After an extended period of inactivity, a memory reset was carried out. Gedpfx Ahowq Duye Dokc The machine was operating without any issues up to the last use. Due to the memory reset, it cannot be demonstrated in operation. The machine is offered with two vices. Sale as defective for repair, retrofit, or as a source of spare parts.

Stanje: zelo dobro (rabljeno), X axis 1200 mm Y axis 600 mm Z axis 850 mm 24-position tool changer Year of manufacture: 2000 Spindle speed: 9000 rpm Gksdjwmaadopfx Ah Doc Internal coolant supply: 32 bar

Stanje: zelo dobro (rabljeno), Model: F30 Delovna površina mize: 1625 x 800 mm, popolnoma vrtljiva preko krmiljenja Krmiljenje: Heidenhain 426 X-os: 1800 mm Y-os: 1150 mm Z-os: 1370 mm Vreteno, stožec: 50 INT Godpfx Aewif Rmjh Dskc Hitrosti vretena: do 1800 vrt/min

Stanje: rabljeno, Leto izdelave: 2018, x-travel 3200 / 2630 mm y-travel 750 mm z-travel 695 / 800 mm Control: Heidenhain TNC 640 Swivel range: -98 to 98 degrees Rotary table diameter: 750 mm Total power consumption: 29 kW Machine weight approx. 16 t Hedelius travelling column machining centre Tiltenta 7 Magnum with infinitely adjustable main spindle, 5-axis CNC control Heidenhain Gksdswfqqkepfx Ah Dsc TNC 640, 22.0 kW/117 Nm main spindle drive 50-12000 rpm, 50-position tool magazine and NC rotary table integrated in the fixed machine table. Machine features: T7M-3200, operating mode 3 - High-pressure pump 50 bar - Heidenhain TNC 640-T series - Spindle speed 12,000 rpm / 29.0 kW - Extended swivel range TNC/T - Remote control HR 510 - Standby magazine SK40/190 - Taper cleaning station - Slant-bed coolant system 900 l - Internal coolant supply 25 bar - Pre-filter for slant-bed coolant system - Electrostatic exhaust filter T / 2x1300 - Compressed air nozzle at spindle head - Internal compressed air supply - Blow-off guns - Rinsing guns - Infrared receiver M&H 91.40 - 3D infrared measuring probe M&H 25.50 - Tool setter M&H 35.70 - Work area partition T7 with sliding door Control on: 33163:56:22 Machine on: 24185:07:21 Program runtime: 16784:12:57 Spindle: 11751:13:08

Stanje: dober (rabljeno), Leto izdelave: 2003, Vertikalna rezkalna stroj UNITECH Tip: FSS 315-S7 l.2003 s 3-osnim digitalnim prikazovalnikom ACU-RITE Hidravlično vpenjanje orodja, sinhrona rezkalna enota, hladilni sistem. Gkodpfxov A Traj Ah Doc Potezne dolžine: X 1000 mm Y 355 mm Z 505 mm Miza: 315 mm x 1250 mm. Vreteno: ISO 50 Število obratov vretena: 28 - 2240 min⁻¹ Stroj v dobrem stanju, dokumentacija stroja na voljo. Dodatni podatki so na voljo v podatkovnih listih.

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2012, obratovalne ure: 12.958 h, številka stroja/vozila: 121113, used milling machine, internal coolant supply 22 bar, chip conveyor, handwheel, technical condition very good. The machine is sold without tools and without accessories. Inspection under power possible at any time. Gkodpfx Aou A A Dceh Doc

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2011, obratovalne ure: 12.214 h, številka stroja/vozila: 111146, The machine is equipped with an IKZ 22 bar. Chip conveyor, handwheel, Heidenhain 530 control. The machine is sold without tools and without a vise. Technical condition is very good; it can be inspected at any time without connection to power. Gkodpeu A Azuofx Ah Dsc

Stanje: dober (rabljeno), Leto izdelave: 2010, BMS 4AL CNC Vertical CNC Milling Machine CNC: ECS 1801 Robust milling machine suitable for a wide range of applications Meehanite cast iron structure Gjdpfx Ahoupg Nus Dokc 5 HP spindle motor with inverter (variable speed) Automatic X and Y axis feed with 1/2 HP motor and inverter Electric elevating table with 1 HP motor Large working surface: 305x1500 mm ISO 40 spindle taper – Quill diameter: 105 mm Square guides on Y and Z axes X and Y axes slideways with Turcite-B Hardened table and guideways

Stanje: potreben popravila (rabljeno), Leto izdelave: 1983, Funkcionalnost: omejena funkcionalnost, skupna višina: 2.650 mm, skupna širina: 3.640 mm, skupna dolžina: 4.620 mm, skupna masa: 6.800 kg, Tehnični podatki: Pomik po osi X: 1000 mm Gkjdpsunwd Tofx Ah Dsc Pomik po osi Y: 560 mm Pomik po osi Z: 800 mm Hitri pomik: 6 m/min Delovni pomik: 1–400 mm/min Ločljivost rotacijske osi (stopinje): 0,001 Krmilna enota: Philips 432 Število vrtljajev vretena: 20–2000 vrt/min Hod vretena: 125 mm Stožec vretena: ISO 50 Moč vretena: 15 kW Pomikalna sila osi X in Z: 8000 N Pomikalna sila osi X in Z: 24000 N Velikost mize: 1250 x 800 mm Nosilnost mize: 800 kg Programska ločljivost: 0,001 mm Dokumentacija za stroj Opomba: Elektronska kartica je v okvari in jo je treba zamenjati. Stroj je mehansko v odličnem stanju in ga je mogoče enostavno nadgraditi z modernimi CNC krmilji.

Stanje: potreben popravila (rabljeno), dolžina podajanja os X: 1.500 mm, dolžina pomika po osi Y: 600 mm, dolžina podajanja os Z: 450 mm, Manufacturer: Reckermann Model: Beta 10 Gkodeuhnznjpfx Ah Dec Travels: X: 1500 mm Y: 600 mm Z: 450 mm Control: Sinumerik 810M The Y-axis does not move; it is not at a reference point.

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2003, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: MATRICOLA N. 196729, No. 1 Mobile Column Milling Machine with transverse travel – 1210 mm, vertical travel – 1000 mm, AC brushless axis motors, AC spindle motor with 20.5 kW power output (S6), 2-range speed transmission, ball screws with preloaded nut on 3 axes, oil cooling and lubrication systems for gearbox and milling head, safety electromagnetic brake on vertical axis, linear guides with roller carriages, hydro-pneumatic counterweight, axis feed rate 25 m/min. Longitudinal travel: 3000 mm Table size: 3200 x 710 mm Equipped with SELCA S4045D CNC control, portable electronic handwheel, high-performance CPU for SELCA system. Gksdpfst I Tr Hex Ah Dsc Automatic Universal Birotary Head KOSMO 5000, 5000 rpm, ISO 50 taper. FAEMAT FA 120 CU electrospindle, 30,000 rpm, 10 kW, 3 Nm torque.

Stanje: rabljeno, Leto izdelave: 1979, x-axis travel 1800 mm y-axis travel 1200 mm z-axis travel 900 mm Gksdpfx Aet Hw Eneh Doc Total power requirement 50 kW Machine weight approx. 15 t Space requirement approx. [ ] m BOHNER & KÖHLE Universal Milling Machine for toolmaking with HEIDENHAIN CNC control Model: WF 3 / 12 TNC 426 Year of manufacture: 1979 / modernised in 1999 Serial No.: 178 Table size: 1,600 x 1,200 mm Table travels: Longitudinal (X): 1,800 mm Cross (Y): 1,200 mm Rotary (manual): 360° Max. table load: approx. 4,000 kg Vertical slide travel (Z): 900 mm Vertical milling head travel (W): 300 mm Milling head swivelling: 2 x 90° Distance from spindle nose to table: 1,000 mm Spindle overhang: 1,230 mm Max. workpiece diameter for rotary milling: 2,100 mm Spindle taper: SK 50 Infinitely variable spindle speeds: 0 – 3,200 rpm Milling head feed per revolution: 0.04 - 0.4 mm/min Table feeds longitudinal & cross (infinitely variable): 100 – 4,000 mm/min Creep feed: 2 - 8 mm/min Rapid traverse: up to 10,000 mm/min Spindle drive: 22 kW; total drive approx. 50 kW - 380 V - 50 Hz Weight: approx. 15 t Accessories / Special Features: • HEIDENHAIN CNC path control type TNC 426 CB for 4 axes (?). Originally supplied as a mechanical machine and retrofitted in 1999 with above-mentioned control. Operation by swing control panel with monitor. • Hydromechanical clamping for traverse axes, hydraulic oil cooler. • Approx. 20 SK 50 tool holders, angular milling head, electric tool clamp, • Lateral supports for the worktable, separate control cabinet, • Rotary table can be manually turned and positioned. • RS 232 or RJ 45 interface for direct programming. Condition: good – ready for demonstration, robust and very user-friendly machine Delivery: ex-stock – as inspected Payment: net – upon receipt of invoice We look forward to your order. Further milling machines and machining centers of all types and sizes available from stock at any time!

Stanje: rabljeno, CNC 5-Axis HMC – Horizontal Machining Center, Milling Center, Production Center Manufacturer: LICON Model: Liflex 1266 PC B1 Year of construction: 2016, Commissioned: 2017 Equipped with SIEMENS 840D SL CNC Path Control (Solution Line) with 5 simultaneously controlled axes Travel distances: X: 1200 mm, Y: 660 mm, Z: 650 mm A-axis as a swiveling bridge +/- 135° (270° total) B-axis 360° infinite rotation Axis acceleration X + Y axis: 6 m/s² Axis acceleration Z axis: 9 m/s² Feed force X + Y axis: 7500 N Feed force Z axis: 10,000 N Positioning tolerance (X/Y/Z): 0.008 mm Swivel speeds A-axis: 180° rotation in 4 sec. Interference circle diameter in swing bridge: max. 1400 mm Transport load in swing bridge: max. 700 kg Tool holder: HSK 63 Spindle speed: max. 12,000 rpm, stepless Spindle power: 37 kW at 40% duty cycle Spindle torque at 40% duty cycle: 85 Nm Max. spindle torque: 100 Nm Tool change time (chip to chip): approx. 3.7 sec. Tool diameter with adjacent slots occupied: Ø 140 mm Tool diameter with adjacent slots empty: Ø 250 mm Max. tool length: 400 mm Max. tool weight: 20 kg Power supply: 400 Volt, 50 Hz Connected load: 80 kVA Compressed air connection: 5–8 bar - LIFLEX MSP 80/63/85/12,000 motor spindle (power 37 kW/40% duty cycle) with liquid cooling and recooling unit - LICON 2-axis rotary tilting table as B and C axis, with hydraulic axis clamping - Zero-point clamping system on the rotary table of the tilting axis - Double pallet changer, without pallets (must be procured separately) - Media transfer for 5 single-acting pressure lines for oil or air for workpiece clamping on pallets. Hydraulic functions range from 30–150 bar, pressure monitoring (controllable via M functions) - Tool changer with 30 positions, disc-type turret - Machine configured for dry machining with MMS minimum quantity lubrication system - MMS-IKZ, internal MMS lubrication supply through spindle - Drag-chain chip conveyor, discharge height 1150 mm - Licon ECO Mode (energy efficient operation) Gkjdpst Ac Efefx Ah Dsc - Direct path measuring system in all axes - Recorded operating hours with control voltage on: approx. 7,500 h Operating space required (L x W x H): 9000 x 5000 x 3800 mm Transport space required (L x W x H): 6100 x 4400 x 3600 mm Weight of base machine: approx. 21 t Total weight: approx. 24 t Very good condition

Stanje: rabljeno, The machine has a defect on the main spindle CNC Vertical Machining Center CHIRON Type FZ 22 L high speed Machining center with FANUC Series 21-M CNC control Serial No. 179-98 Year of manufacture: 1999 Travel paths X: 2000 mm, Y: 520 mm, Z: 630 mm Table size 2700 x 570 mm Table load 525 kg (per meter) Tool holder SK 40 (DIN 69871) Drilling capacity 35 mm Tapping capacity M27 Tool diameter 75 mm Diameter with free adjacent pockets 105 mm Tool change time Tool-to-Tool 2.0 sec. Tool change time Chip-to-Chip 4.8 sec. Distance spindle nose - table 190 to 820 mm Spindle speed max. 10,500 rpm Main spindle drive max. 18.5 kW Power supply 400 Volt, 50 Hz, 32 kVA - Pendulum machining over 2 working areas (partition wall missing) - CNC control FANUC Series 21-M - 40-position tool changer - ICS = Internal coolant supply through the spindle - Splash guard cabin with sliding door - Indirect linear measuring system - Coolant unit with side-mounted chip conveyor - Electronic handwheel Transport dimensions of the base machine L x W x H 4600 x 2470 x 2950 mm Machine weight approx. 7.5 tons Transport space required on truck L x W x H 12000 x 2470 x 2950 mm Transport weight on truck approx. 10 tons Gksdpfxjquhbge Ah Dsc Weight 7.2 tons good condition – the machine has a defect on the main spindle

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2001, CNC Milling Machine TOS TV-1000 A CONTUR Gjdpfjhlp Iwsx Ah Djkc Manufacturer: Trens Model: MC 100 VA Year of manufacture: 2001 Condition: Used Control unit: Heidenhain TNC 426 X-axis travel: 1000 mm Y-axis travel: 600 mm Z-axis travel: 760 mm Table length: 1080 mm Table width: 580 mm Tool changer with 40 positions Tool holder according to ISO 40 Spindle speed: 8000 rpm Overall dimensions: L 3200 x W 2100 x H 2900 mm Weight: 6200 kg Shipping available throughout Germany and Austria. Surcharge: €1,000 Sale excludes any warranty.

Stanje: dober (rabljeno), Leto izdelave: 1990, 1 used, well-maintained CNC-controlled tool milling machine in travelling column design with GRUNDIG Dialog 11 CNC path control Table size 1600 x 675 mm Tool holder SK / ISO 40 Travel paths X-axis, longitudinal 1200 mm Y-axis, cross 600 mm Z-axis, vertical 500 mm Table load 2000 kg Spindle speed range 20 – 6300 rpm Feed range, stepless 2 – 10,000 mm/min Rapid traverse on all axes 10 m/min Quill stroke 80 mm Drive power 100% duty cycle 7.5 kW 40% duty cycle 12 kW Machine dimensions (L x W x H) 3600 x 3000 x 2300 mm Machine weight 6800 kg Control cabinet dimensions (L x W x H) 1700 x 900 x 1750 mm Control cabinet weight 470 kg Accessories / Special features: • CNC tool milling machine suitable for toolmaking, jig & fixture construction, training, as well as mold making • GRUNDIG Dialog 11 CNC path control • Screen graphics, dialog-guided input, 3D linear interpolation, circular interpolation, helical interpolation, polar coordinate input, numerous drilling and milling cycles, graphical cycle input support, “contour pocket” milling cycles for the automatic clearance milling of irregular pockets including with islands, shifting and rotating the coordinate system • Electronic handwheel • RS 232 interface • Swiveling vertical milling head +/- 90° Gsdpfx Aehhuf Hoh Dekc • Hydraulic tool clamping, DIN 2080 with clamping groove, Ott system • Adjustable quill, 80 mm • Horizontal milling device • Fully enclosed safety cabin • Ball screws in all 3 axes • Coolant system • Lighting Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 D - 44143 Dortmund - Wambel

Stanje: zelo dobro (rabljeno), Manufacturer: SHW Werkzeugmaschinen Model: UF 21 / UF 31 / UF 41 Travel X, Y, Z: 1000, 700, 625 mm Control: Various versions of Heidenhain TNC 155, TNC 355, TNC 426, iTNC 530 Table: NC rotary table 1100 x 840 mm or fixed angle table Automatic universal milling head Quill stroke: 120 mm Spindle taper: SK 50 Spindle speed: 2,500 rpm Gedpfx Ajftc Uxeh Dekc Please note, as we offer multiple machines from this series, the images shown are sample images of comparable models only. We invite you to send us your individual enquiry (controller, table size, tilting/rotary device, etc.) so we can provide a machine tailored to your requirements. MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our core focus is on tool milling machines. Our services include spare parts supply, on-site customer service, machine overhauls, and CNC control upgrades. Services: - Used machines - Spare parts - Customer service - Machine service - Machine overhauls - Control upgrades _____ Used machine - second-hand milling machine - universal milling machine - swivel head - metalworking - tool milling machine - milling head - SHW machine - console milling machine - rotary table - NC rotary table - SK50 - SHW spare parts - used milling machine - used CNC milling machine - used drilling milling machine - used metal milling machine - used metal mill - used CNC mill - CNC milling machines - SHW UF - Heidenhain - MBM milling machine - MBM machine
