Polska Grupa Cnc Pc1530 nakup rabljenega (15.968)

Stanje: rabljeno, Leto izdelave: 2016, Used machine Year of manufacture: 2016 Equipment and technical data: - Electrical system 3x400V 50/60Hz - Cardanic 5-axis electrospindle 12 kW (S6) HSK F63 - 24,000 rpm - Ceramic bearings including liquid cooling with infinitely variable height-adjustable extraction hood – motorized control - Full nominal power at approx. 12,000 rpm - Speed range: 1,000 - 24,000 rpm - Drive: 3-phase high-frequency motor, inverter-controlled - Rotation direction: right/left - 2 controlled compressed air connections - Interface for aggregates - Tool weight (rotating): 6 kg - Max. saw blade Ø 350 mm - Spindle cooling: liquid cooling - Continuously adjustable extraction hood - Profit H350 16.30: CNC machining center in gantry design (without tools), featuring digital drives (driven on both sides). The machine frame of the Profit H350 16.30 is made of thick-walled, electro-welded box sections. The steel ribbing inside the frame ensures high stability. - Machining area H350 16.30: Travel axes: X = 4000 mm Y = 1970 mm Z = 455 mm Working field: X = 3000 mm Y = 1500 mm Z = 150 mm pass-through height Axis positioning speeds: Depend on the selected safety system (see layout for details). - Dual-drive gantry - X-axis guidance system: Dkedoy Ih Rgspfx Ab Hjn The drive for the X-axis gantry is via a rack-and-pinion with helical crowned teeth – ensuring maximum precision. The reduction gearbox provides the highest machining and repeat accuracy. Bearings are precision, encapsulated ball bearing carriages running on hardened and ground linear guides. - Y-axis guidance system: Bearings are precision, encapsulated ball bearing carriages running on hardened and ground linear guides. The Y-axis is positioned via a ground ball screw. - Z-axis guidance system: Bearings are precision, encapsulated ball bearing carriages running on hardened and ground linear guides. The Z-axis is positioned via a ground ball screw. - Automatic central lubrication system: Grease is automatically and precisely delivered to the guide carriages of the X, Y, and Z axes as well as to the ball screws of Y and Z. Lubrication cycle is performed automatically after a defined interval. - 12-position linear tool changer on the left of the machine frame including a pickup station for aggregates: The 12-position linear changer ensures minimal changeover times and provides sufficient space for milling tools. One aggregate station (configuration options, see layout). Max. tool diameter: 250 mm Max. tool length: 240 mm - Drilling head DH 18 6H 1S: Vertical 12 spindles: 7 spindles in X-direction and 5 spindles in Y-direction. Horizontal 6 spindles: 4 spindles in X-direction and 2 spindles in Y-direction. Stroke = 70 mm Max. drill bit length = 70 mm, shank diameter = 10 mm. All spindles are individually driven and selectable. 1 grooving saw – X-direction Max. saw blade diameter: 120 mm Max. bla...

Stanje: pripravljen za uporabo (rabljen), Leto izdelave 2006 / AWZ / takoj na voljo / Lokacija: Salzburg Dsdpfxeza Ugkj Ab Hjkn

Stanje: rabljeno, Leto izdelave: 2009, x-travel: 4000, y-travel: 2000, z-travel: 600 Dimensions (LxWxH): 6,400 x 3,200 x 3,100 mm Weight approx.: 10,500 kg Waterjet Cutting System Stein-Moser GmbH CNC 5-axis 4020 x 2020 x 600 mm Technical Data: - Working area X, Y 2D: 4,020 x 2,020 mm - Support surface X, Y: 4,400 x 2,400 mm - Z-axis: 600 mm - Swivel range A, B: +/- 46° - Rotary axis C, 360° rotation: +/- 3,600° - Positioning speed: 10 m/min - Repeat accuracy: +/- 0.1 mm - Pneumatic connection: min. 6.5 bar - Water connection: 2 – 5 bar - Machine dimensions LxWxH: 6,400 x 3,200 x 3,100 mm - Weight (with water): approx. 10,500 kg - Operating temperature: +10°C to +40°C - Max. operating pressure, high-pressure waterjet component: 4,000 bar TOOLS / SPARE PARTS WORTH approx. €25,000 INCLUDED. New price approx. EUR 300,000 for the waterjet cutting system. Includes 3 tons of cutting sand. Serial: WS2040HB/090601 Type: WS 2040 HB Tank 4.2 PC cabinet (Rittal) on castors with air conditioning unit, contains: servo controller, TYM NUM AXIUM POWER, NUM MDLU 3 drive system, control PC, monitor, splash-proof keyboard and mouse, handheld control device for manual machine operation. - Connection values: 400 V AC, 16 A - Control voltage: 24 V DC NUM AXIUM POWER servo controller: - Central unit for CNC, PLC, and communication functions - Decentralized I/O modules with 32/32 digital inputs/outputs via fiber optics MDLU 3 drive system: - Fully digital, compact, integrated power supply - Integrated position, speed, and current control - Brushless digital servomotors - High-resolution measurement system via integrated SinCos encoder - Motor rated power: 2 kW CAD/CAM software Complete package for creating or importing drawings, setting process-specific parameters for the waterjet, and controlling the machine. - Direct machine control - 32-bit Windows software - Automatic approach strategies - Automatic correction sequence - Cutting direction freely selectable for each contour - Jet correction - Material database Dedpjwiatijfx Ab Hskn - Visual cut monitoring - HPGL and DXF import - Automatic pump pressure setting

Stanje: rabljeno, Leto izdelave: 2003, Premer žaginega lista 300x32x2,5 mm Območje reza pri 90 stopinjah: okroglo 10-90 mm Območje reza pri 90 stopinjah: ploščato 80x10-80 mm Območje reza pri 90 stopinjah: kvadratno 10-80 mm Dkodpfxoyv Nvto Ab Hen Območje reza pri 90 stopinjah: okroglo - polni material 10-40 mm Območje reza pri 90 stopinjah: ploščato - polni material 40x10-40 mm Območje reza pri 90 stopinjah: kvadratno - polni material 10-40 mm Hitrost vrtenja 1700/3400 obr/min Teža stroja cca 600 kg Potrebna površina cca 2590x1910x1910 mm Dodatna oprema: - Nožni pedal z izklopom v sili - Mikro-razpršilna naprava - HM krožna žaga 350 mm

Stanje: rabljeno, Leto izdelave: 2001, Premer žaginega lista 350 mm Odpiranje primeža 190 mm Število vrtljajev 15 / 30 / 45 / 90 min⁻¹ Djdpsyvvpmjfx Ab Hjkn Pogonska moč 1,8 / 2,6 kW

Stanje: dober (rabljeno), Leto izdelave: 2005, Maks. premer struženja 500 mm Dolžina struženja 550 mm Premer vretena 65 mm Hitrost vrtenja 5.000 min⁻¹ Dsdpfxszbaq Dj Ab Hjkn Vključuje podajalnik palic

Stanje: rabljeno, Leto izdelave: 2005, Obdelovalna dimenzija: 3000 x 1600 x 180 mm Visokotlačna črpalka 60 KM / 45 kW Model E-60 Delovni tlak 4.130 BAR Poraba vode 4,69 litra/min. Programska oprema Watercad-CAM Samodejna optimizacija reza Dkjdpfx Aboxgfbqs Hon Lokacija zaloge: Stranka

Stanje: kot nova (razstavni stroj), Leto izdelave: 2022, Funkcionalnost: popolnoma funkcionalen,

Stanje: pripravljen za uporabo (rabljen), Leto izdelave: 2015, obratovalne ure: 43.196 h, Funkcionalnost: popolnoma funkcionalen, potovalna razdalja osi X: 165 mm, pomik osi Y: 80 mm, model krmilnika: Fanuc 310 is, največja hitrost vretena: 5.000 obr/min, največja hitrost protivretena: 5.000 obr/min, No reserve price – guaranteed sale to the highest bidder! CNC Turning Center with comprehensive accessories! A wide range of nearly new spare parts is also available! TECHNICAL DETAILS Travel X1 axis: 165 mm Travel X2 axis: 165 mm Travel Y1 axis: 80 (+50 / -30) mm Travel Z1 axis: 678 mm Travel Z2 axis: 640 mm Travel W2 axis: 690 mm Rapid traverse X/Y/Z/W axis: 30 m/min Acceleration X/Y/Z/W axis: 5 m/s² Main and counter spindle Main spindle power: 20 / 25 kW Counter spindle power: 17 kW Max. main spindle speed: 5,000 rpm Max. counter spindle speed: 5,000 rpm Max. main spindle bar capacity: 65 mm Max. counter spindle bar capacity: 45 mm Number of turrets: 2 Number of live tools per station: 12 powered positions Tool system: VDI 30 Driven tool speed: max. 4,000 rpm MACHINE DETAILS Control: Fanuc 310 is Coolant tank capacity: approx. 650 l Coolant pump capacity per turret: max. 20 l/min Pump pressure: 7 bar Connected load: 91 kVA Dimensions & Weight Machine dimensions (L x W x H): 4,500 x 1,990 x 2,300 mm Machine weight: approx. 9,500 kg Operating hours Power-on hours: 64,274 h Operating hours: 43,196 h Dsdpjza Alhofx Ab Hskn EQUIPMENT IEMCA MASTER 865 MP 43 L bar feeder Drive for slide 1 and 2, all 12 positions C-axis for main and counter spindle Y-axis for slide 1 Chip conveyor, belt type Counter spindle collet cleaning with coolant Part ejection including conveyor belt Mechanical preparation for oil mist filter Electrical and software interface for bar feeder Angular synchronisation between main and counter spindle Automatic machine shutdown 2 additional inputs/outputs, 4 M-functions Thread cutting without compensation chuck Piece and time counters Polygon turning software for slides 1 and 2 Constant cutting speed Helical interpolation for slide 1 Spindle speed monitoring Four-color warning beacon Cooling unit for control cabinet Collet chuck type MPF 65/140 without axial feed for main spindle, max. diameter 65 mm Manual collet changer type SACO MPT65/140 and MPF65/140 Differential pressure for counter spindle with capability to set two different clamping pressures 1 set of soft jaws for chuck type SMW 175-BBD Chuck type SMW 175-BBD for counter spindle including spindle adapter Tool wear monitoring system for CNC FANUC Sister tool selection system for Tool Monitor CNC FANUC External flushing of jaws and collets with coolant on main and counter spindle

Stanje: kot nova (razstavni stroj), Leto izdelave: 2023, višina orodja: 200 mm, Kot upogiba (maks.): 180 °, stiskalna sila: 42 t, najv. debelina pločevine: 30 mm, najv. debelina bakrene pločevine: 20 mm, hitrost dviga: 10 mm/s, upogibna sila (maks.): 42 t, Stierli Bieger 420 CNC Horizontalni upogibni stroj s Siemens krmiljenjem. Zelo univerzalna horizontalna stiskalnica, primerna za upogibanje ploščatega jekla, pločevine, okroglega jekla, profilov, cevi kvadratnih ali okroglih, oblikovanih orodij ter enostavno pritrditev lastnih orodij ali posebnih orodij. Možna je tudi funkcija ravnanja kot ravnalna stiskalnica. Dsdpfx Ajgqflqjb Hskn Upogibna sila 42 ton Višina orodja 200 mm Dolžina upogibnega hoda 0-300 mm brezstopenjsko nastavljiva Zmogljivost upogibanja 200x24 mm S235 Ravnalna zmogljivost za HEA180 Upogibni in ravnalni program preko izbirnega stikala Demonstracijski stroj, letnik 2023, vključno z ročnim in nožnim pedalom Horizontalna upogibna stiskalnica kot nova Kontaktirajte nas za dodatne informacije o tem horizontalnem upogibnem stroju.

Stanje: skoraj kot novo (rabljeno), Leto izdelave: 2024, višina orodja: 130 mm, najv. debelina bakrene pločevine: 20 mm, upogibna sila (maks.): 12 t, Stierli Bieger 120 CNC Horizontalni upogibni stroj, Siemens krmiljenje Dkedpjflc R Uefx Ab Hen Zelo univerzalen, za ploščato jeklo, pločevino, okroglo jeklo, profile, cevi kvadratne ali okrogle, oblikovna orodja ter enostavna pritrditev lastnih ali posebnih orodij. Upogibna sila: 12 ton Višina orodja: 130 mm Zmogljivost upogibanja: 130x12 mm S235 Izravnalna zmogljivost: lažja izravnalna dela Upogibanje cevi: 3/8"-1 1/2" Merilna dolžina prislona: 1000/2000 mm Shranjevanje programov: 200 programov Kompleti upogibov: 20 upogibov Demonstracijski stroj letnik 2024 z ročno in nožno stopalko Stroj kot nov

Stanje: kot nova (razstavni stroj), Leto izdelave: 2024, premer vrtljive mize: 390 mm, Kot upogiba (maks.): 360 °, Stierli Bieger Radial 2500 CNC Radial bending machine with large rotary table for bends up to 360° Dkedpfxjgqfp Ho Ab Hsn Bending moment: 2500 Nm Bending capacity for flat steel: 60x15 mm (S235) Bending capacity for round steel: ø30 mm (S235) Rotary table diameter: 390 or 550 mm Demonstration model, year 2024, incl. hand and foot pedal Machine in as-new condition Operates like a classic manual bender, but powered, highly precise and programmable. Includes manual or programmable CNC backgauge, available in 1, 2, or 3 meters length. Bending angles and backgauge positions are digitally programmable and can be stored in bending programs. The standard tooling uses simple bending pins. A driver bends the material around these pins. These tools can be easily manufactured by the customer. In addition to standard bending pins, we (or our customers) also manufacture tools for other cross-sections. Suitable for bending sheet metal, flat steel, round steel, various profiles, frames, etc. Clamping jaws can also be mounted, allowing for very small radius bends (similar to a manual bending device). This machine solves your bending requirements!

Stanje: rabljeno, številka stroja/vozila: 008362, Delovno območje os X: 3200 mm Delovno območje os Y: 1600 mm Delovna površina: z vakuumskimi konzolnimi podlagami Moč glavnega vretena: 12 kW Število krmiljenih osi: 5 osi Število vrtalnih vreten: 32 Dodpfx Absx A Tl As Hskn Število mest za orodja: 22

Stanje: rabljeno, številka stroja/vozila: 008370, Delovno območje os X: 5055 mm Djdpfox A Tk Sjx Ab Hokn Delovno območje os Y: 1930 mm Delovna površina: z vakuumskimi konzolnimi podstavki Moč glavnega vretena: 19 kW Število upravljanih osi: 5 osi Največja višina roba: 60 mm Število vrtalnih vreten: 28 Število mest za orodja: 31

Stanje: rabljeno, številka stroja/vozila: 008340, Delovno območje os X: 4400 mm Delovno območje os Y: 1300 mm Delovna miza: S podstavki z vakuumskimi konzolami Moč glavnega vretena: 11 kW Število krmiljenih osi: 5 osi Število vrtalnih vreten: 36 Število mest za orodje: 30 Dodjy Nkpnopfx Ab Hskn

Stanje: rabljeno, Leto izdelave: 2017, Tehnični podatki: Premer struženja: 340 mm Dolžina struženja: 1000 mm Krmiljenje: OSP 300 LA Premer nihanja nad prečnim suportom: 470 mm Največji krožni premer nad posteljo: 580 mm Pomik - x: 260 mm Pomik - z: 1065 mm Hitri pomik - vzdolžno/čelno: 30 / 25 m/min Premer palice: 52 mm Premer vretena: 80 mm Hitrost vretena: 5000 1/min Motor vretena: 22 / 15 kW Revolver postaje / od tega gnane: 12/12 VDI 40 Pogonska moč gnane orodja: 7 kW Hitrost gnane orodja: 6000 1/min Pomik konjička: 1015 mm Konjiček – pritrditev pinole MK: 5 Skupna priključna moč: 38.7 kVA Teža stroja cca.: 6500 kg Potrebni prostor cca.: 4 x 2,5 x 2 m Dodszb Rh Hjpfx Ab Hokn Oprema: Odvajač ostružkov Signalna lučka 2-kratna Ročna ročna merilna ročica orodja Visoko zmogljiv natančni stružni center z gnanimi orodji in C-osjo. Sistem vpenjalne gredi Steifelmayer za votle gredi je mogoče nadomestiti z običajnim Kitagawa vpenjalnim tulecem premera 250 mm. - Stroj je mogoče prikazati pod napetostjo.

Stanje: rabljeno, Leto izdelave: 2005, 2005 BIESSE ROVER B 4.40 FT CNC obdelovalni center s 3 osmi Dkodpfoy Ud Sgox Ab Hon Tehnične značilnosti na zadnji fotografiji Delovne ure stroja: 45.343 Ure v avtomatskem načinu (delo): 27.267

Stanje: rabljeno, Leto izdelave: 2011, AXES Working area X-Y-Z axes * mm: 3050-1300-180 Workpiece length in pendulum operation mm: 1390 Stroke X-Y-Z axes mm: 3460-1735-250 Max. traverse speed X-Y axes m/min: 60 WORK TABLE Number of workpiece supports and vacuum suction pads: 6 / 2 standard type Standard end stops / position: 1 / rear Vacuum pump m³/h: 90/108 DRILLING UNIT Vertical spindles std./number/speed rpm: 12 (8X-5Y) / 4000 Horizontal spindles std./number/speed rpm: 6 (4X-2Y) / 4000 Integrated grooving / saw unit in X Ømm/rpm: 120 / 6000 Motor power kW (hp): 2.2 (3) ELECTROSPINDLE Motor power std. / opt. (S6) kW (hp): 7.5 (10) / 11 (15) Max. speed rpm: 24,000 Tool changer, traveling with the support in X: 4 positions, pneumatic INSTALLATION Installed power KVA: 23–28.5 Compressed air requirement Nl/min: 450 Extraction air requirement m³/h: 1900+1900 (3400) Required extraction air speed m/sec: 30 Extraction port diameter mm: 150+150 (200) Machine weight kg: 3000 * X Distance between stops – Y cutter center as reference; Z workpiece passage GENERAL FEATURES CNC-controlled drilling and milling center in frame design with work table equipped with adjustable workpiece supports and vacuum suction pads, suitable for: - Vertical drilling on the panel surface Dkodpfx Abjyymz Us Hon - Horizontal drilling on all four panel sides - Groove milling with disc cutter in the X direction - General milling operations Self-supporting structure and work table: Steel welded frame construction with the control cabinet integrated into the machine frame. Available in two different lengths and with standard workpiece supports or optionally different support carriers. Box-type construction made from cold-rolled steel with internal reinforcement ribs, protective covers with component group consisting of a drilling head with vertical and horizontal spindles, integrated grooving and saw unit, and an SCM electrospindle with quick-change tool system type HSK 63 F. Travel paths of the portal and support carrier: Movement in the X, Y, and Z axes takes place on linear prismatic recirculating ball guides with preloaded bearings. Movement transmission of the X-axis (moving stand) is via a preloaded, backlash-free rack-and-pinion drive with helical gears. Movement of the support carrier in Y and Z directions is via preloaded ball screws. Positioning of the working units and machine functions is managed by "brushless" AC servomotors and digital drives. CNC CONTROL UNIT The control unit consists of a numerical control for milling and drilling machines and a connected PC with a graphical user interface "XILOG PLUS". - PC-Office operating system Windows XP - Color LCD screen 17" - QWERTY keyboard - Swivelling control panel - Machine interface software Xilog Plus Xilog Plus features: Programming - Parametric, graphical and ISO programming - Import of DXF and ASCII files - Straight line or circular interpolation in three axes, linear in space, spiral on the chosen plane - Assisted programming with graphical and syntax help for drilling and milling operations - Automatic optimization of drilling operations and tool change cycles - Possibility to shift panel zero point for drilling on inclined or curved panel edges - Full compatibility with CAD/CAM Routocam (SCM) – AlphaCam Integrated additional features - Calculator for direct data transfer - S

Stanje: rabljeno, številka stroja/vozila: 008480, Delovno območje os X: 4600 mm Delovno območje os Y: 1550 mm Delovna površina: z vakuumskimi konzolami Dkjdpfxoy Edqko Ab Hjn Moč glavnega vretena: 18 kW Število krmiljenih osi: 5 osi Število vrtalnih vreten: 31 Število mest za orodje: 58

Stanje: zelo dobro (rabljeno), Leto izdelave: 2016, Krmiljenje Siemens 840 SL, dvo-vretena 20.000 o/min, HSK 63, 2x 32 orodnih mest, notranje hlajenje 30 bar, X 550 mm, Y 400 mm, Z 400 mm, neposreden merilni sistem, naprava za menjavo obdelovanca, laserski nadzor, hladilni sistem Knoll, izpiranje naprave, centralno mazanje, samodejna nakladalna vrata, leto izdelave 2016 Djdpjzb D Rnefx Ab Hekn

Stanje: zelo dobro (rabljeno), Leto izdelave: 2024, MAZAK INTEGREX i-100H Maks. premer obdelave: 600 mm Maks. dolžina obdelave: 590 mm Maks. hitrost rezkanja: 12.000 vrt/min Maks. hitrost vretena: 6.000 vrt/min Stroj je opremljen z: Dodpfx Aoy Hwn Eeb Hjkn - CNC krmiljenjem Mazatrol SmoothAi - Magazin za 74 orodij - Tričeljustno vpenjalo KITAGAWA B-206, premer 169 mm - Tool Eye - Natančnost vnašanja osi C: 0,0001° - Os Y - Os B: 0,0001° - Paket za 5-osno obdelavo za SmoothAi - Ojačana črpalka hladilne tekočine 15 bar - Transporter ostružkov, stranski izmet

Stanje: kot nova (razstavni stroj), Leto izdelave: 2025, Studer S40 1000/1600 Grinding length: 1,000 / 1,600 mm Dksdpfx Ajfg S Uajb Hon Centre height: 175 mm (optionally higher) Workpiece weight: 120 kg Additional configurable options: - Completely new control cabinet with Siemens Sinumerik One or Fanuc 0iTF-Plus CNC - Fast setup via GSN operator interface - B-axis freely positionable - Second external grinding wheel - Internal grinding unit - Increased centre height - Dressing spindle for diamond form roll - Balancing and touch sensor systems - Tailstock hydraulic clamping / unclamping - Automatic Siemens door drive - 19" / 22" monitor - Remote maintenance - Conversion for needle nozzles - Matching coolant/extraction system - Automation preparation - and much more We are also happy to overhaul your existing stock machine! Schaudt / Studer / Kellenberger / Bahmüller / Voumard / Overbeck / Fortuna / Tacchella and others.

Stanje: generalkompletno obnovljen (rabljeno), Leto izdelave: 2025, Schaudt PS51 S600 – Premium Refurbished - Grinding length: 600 mm - Centre height: 180 mm - Grinding wheel width: 220 mm (optionally more possible) - Workpiece weight: 200 kg Further selectable options: - Completely new control cabinet with Siemens Sinumerik One or Fanuc 0iTF-Plus - Rapid setup via GSN operator interface - In-process measuring control DMK / LMK - Dressing spindle for diamond form roller - Balancing and acoustic touch sensor systems - Hydraulic tailstock clamping/release - Automatic Siemens door drive - Remote maintenance - Conversion to needle nozzles - Matching coolant / extraction system - Automation preparation - and much more Dkedpofg Utdjfx Ab Hon We are also happy to overhaul your existing stock machine! Schaudt / Studer / Kellenberger / Bahmüller / Voumard / Overbeck / Fortuna / Tacchella and more.

Stanje: delavnici obnovljeno (rabljeno), Leto izdelave: 2010, obratovalne ure: 31.600 h, Funkcionalnost: popolnoma funkcionalen, številka stroja/vozila: 3078, Axis travel Z = 400 mm Y = 200 mm X = 410 mm Power / Thrust Force Z-Y 2.5 kW / 550 daN (optional linear motor = 7.2 kW / 350 daN) X 4.8 kW / > 550 daN Traverse speed X-Y-Z 40 m/min (optional linear motor = 50 m/min) Acceleration X-Y-Z-W 8 m/s² / 0.8 g (optional linear motor = 10.4 m/s² / 1.1 g) Resolution X-Y-Z-W 0.0001 mm MAIN SPINDLE + C1 Power 7.5 kW Torque / peak 22 / 28 Nm Measuring system direct Resolution 0.0001° Accuracy 0.001° Bar capacity Ø 32 mm Turning speed 72,000°/min Clamping force, turning 4,900 N at 6 bar AXIS B (TILTING TOOL SPINDLE AXIS) Power 4.3 kW Torque / peak 119 / 226 Nm Angular travel -25° / +115° Measuring system direct Resolution 0.0001° Accuracy 0.001° Rotational speed 36,000°/min Support torque 200 Nm TOOL SPINDLE Power 5 kW Torque 6 to 800 min⁻¹ Max speed 30,000 min⁻¹ Collet clamping force 2,000 N Locking torque mechanical lock by straight tooth coupling Tool holder taper HSK 40 (A or E) Tool clamping force 1,000 daN TOOL CHANGER Number of stations 30 (for HSK 40) CNC control Fanuc 30i/31i type Y-Axis (cross axis) Stroke 200 mm Power 4.8 kW Feed force 240 daN Resolution 0.0001 mm Max rapid traverse G0 50 m/min Max feed G1 20 m/min Measuring system glass scale Z-Axis (longitudinal axis) Stroke 400 mm Power 7.2 kW Feed force 360 daN Resolution 0.0001 mm Max rapid traverse G0 50 m/min Max feed G1 20 m/min Measuring system glass scale Cooling unit included 8 kW And integration of emergency stop system. Inventory no. 2220114, machine including: CONTROL Fanuc 30i/31i, with 14’’ screen OPTION FOR LINEAR MOTOR FEED for Y and Z axes TURNING-MILLING FUNCTION With integration of an indexing system (8 positions) on the tool spindle, conversion of tool magazine for HSK40-A tooling, spindle speed increase to 5,500 min⁻¹ “PRM” PART REPRISE UNIT, 4 POSITIONS, FOR 6TH FACE MACHINING: When idle, the unit is housed below the main spindle C1. The reprise unit moves along the W-axis, which is parallel to the C-axis. Max speed on W-axis: 40 m/min. Travel on W-axis: 310 mm. Includes: - 2 vices – force at 5 bar: 3,500 N - 1 tailstock INCREASED SPINDLE BORE Enlargement from 1 to 50 mm (main spindle) “RENISHAW” T27 TOOL MEASUREMENT DEVICE Measurement of turning tool length. Routine detection via M-code. Automatic tool breakage detection. TOOL MAGAZINE EXTENSION Capacity increase from 30 to 60 tool stations COOLANT THROUGH SPINDLE 100 bar, 25 L/min, 400L tank PREPARATION FOR HP THROUGH MILLING SPINDLE Mechanical and electrical integration of the turning clutch. WORKPIECE DISCHARGE CONVEYOR Discharge to the left of the machine PAPER BAND FILTRATION SYSTEM CLAMPING SYSTEM FOR F-48 COLLETS ADAPTATION FOR W-20 COLLETS Djdpfx Ajyf Angjb Hjkn PREPARATION FOR BARFEEDER INTEGRATION Unless otherwise stated, all technical data is provided without obligation or guarantee.

Stanje: zelo dobro (rabljeno), Leto izdelave: 2021, Dvojvretena izvedba Dodpozbr Alofx Ab Hokn S frezalno glavo z osjo C z osjo Y S pogonskimi orodji Upravljanje FANUC Series 31i Model 5 Obratovalni premer - 540 mm Obratovalna dolžina - 1040 mm Pomik osi Y 170 mm (+/- 85) Vpenjalno mesto vretena ASA A2-6 Vrtljaji vretena 5.000/min vsako Delitev osi C 0,001° Frezalna glava os B 240° Delitev 0,001° Frezalni vreteno 12.000/min Revolverska glava 12 pogonskih pozicij Magazin orodij 80 pozicij Naprava za delno odvajanje Merjenje orodja Podajalnik palic LNS Sprint 565 S2 Razni dodatki MARCELS MASCHINEN CH
